Mounting
40
5. Saw off the rope at a right angle or cut it off with a bolt cutter.
6. Insert the rope completely into the weight.
7. Screw the set screws into place. Due to the clamping coating of the setscrews
application of a screw locking fluid is not necessary.
Entering the new probe length
After shortening the probe:
1. Go to the Probe settings submenu and perform a probe length correction.
2.
1 Field for the new probe length
For documentation purposes, enter the new probe length into the Quick Setup which
can be found in the electronics housing behind the display module.
6.2.3

Mounting the device

Mounting devices with thread
Levelflex FMP50 PROFIBUS PA
1
A0014241
A0012528
