Configuration Manual
Ascom d41 DECT Handset
2.2.1

Via Chargers

• Connect a desktop charger (DC4) or a rack charger (CR3) via the Ethernet port to the
network.
The charger is by default configured to connect to the network using DHCP. If DHCP is
not used in the network, connect each charger via USB to a PDM Windows Version
and configure a static IP address.
• Start the IMS2.
• Place the handset in a charger that is connected to the IMS2.
Figure 2. Configuration of handsets via IMS2 and chargers.
2.2.2

Over-the-air via IP-DECT

There is no external equipment needed besides IMS2 and IP-DECT. Please proceed with
3 Installation of Handsets
Figure 3. Configuration of handsets via IMS2 and over-the-air.
2010-01-28/ Ver. D
Figure 2.
IP
IMS2
on page 5.
Figure 3.
Ascom
IP-DECT
System
IMS2
TD 92641GB
Client
IPBS
Client
4
