Series 45 E Frame Open Circuit Pumps
Technical specifications
General specifications
Features and options
Feature
Maximum Displacement
Flow at rated speed (theoretical)
Input torque at maximum displacement (theoretical)
Mass moment of inertia of internal rotating
components
Weight
Rotation
Mounting
Auxiliary mounting
System ports (type)
System ports (location)
Control types
©
Danfoss | September 2016
All manuals and user guides at all-guides.com
Type of mounting
SAE-C mounting flange.
Auxiliary mounting pad options
SAE-A, SAE-B, SAE-B-B, SAE-C, SAE C-C
Control options
PC: Pressure Compensator
LS: Load Sensing (with PC)
Port options
Inlet and system ports:
•
SAE flanged ports, code 61 Inlet Code 62 outlet.
•
Axial (end) ports or radial (side) ports.
All other ports:
•
SAE straight thread O-ring boss.
Direction of rotation
Clockwise or counterclockwise.
Installation position
Installation position is discretionary. To satisfy inlet pressure conditions, it is recommended that the
pump always be located below the lowest level of hydraulic fluid in the reservoir. The housing must
always be filled with hydraulic fluid.
Technical specifications
Unit
cm³ [in³]
l/min
[US gal/min]
N•m/bar
[lbf•in/1000 psi]
kg•m²
[slug•ft²]
Axial ports
kg [lb]
Radial ports
Model
E100B
E130B
100 [6.10]
130 [7.93]
245
286
[64.7]
[75.6]
1.592
2.069
[972]
[1263]
0.0128
0.0128
[0.0094]
[0.0094]
51.3 [113]
54.9 [121]
Clockwise, Counterclockwise
SAE-C
SAE-A, SAE-B, SAE-BB, SAE-C, SAE-CC
4-bolt split flange
Axial, Radial
PC, Remote PC, LS, LS with internal bleed
E147C
147 [8.97]
309
[81.6]
2.340
[1428]
0.0128
[0.0094]
AX00000024en-US0401 | 9
