Technical Information
H1 Axial Piston Single Pumps, Size 147/165

Technical specifications

H1 Pump General Specification

Design
Direction of rotation
Pipe connections
Recommended installation
position
Auxiliary cavity pressure

H1P 147/165 Technical Data

© Danfoss | May 2017
Axial piston pump of cradle swashplate design with variable displacement
Clockwise, Counterclockwise
Main pressure ports: ISO split flange boss
Remaining ports: SAE straight thread O-ring boss
Pump installation position is discretionary, however the recommended control position is on the top or at the side
with the top position preferred.
If the pump is installed with the control at the bottom, flushing flow must be provided through port M14 located on
the EDC, FNR and NFPE control.
Vertical input shaft installation is acceptable.
If input shaft is at the top 1 bar case pressure must be maintained during operation.
The housing must always be filled with hydraulic fluid.
Recommended mounting for a multiple pump stack is to arrange the highest power flow towards the input source.
Consult Danfoss for nonconformance to these guidelines.
Will be inlet pressure with internal charge pump. For reference see
Will be case pressure with external charge supply. Please verify mating pump shaft seal capability.
Feature
Displacement
Flow at rated (continuous) speed
Torque at maximum displacement
(theoretical)
Mass moment of inertia of rotating
components
Mass (dry)
Oil volume
Mounting flange
Input shaft outer diameter, splines and
tapered shafts
Auxiliary mounting flange with metric
fasteners,
Shaft outer diameter and splines
Suction port
Main port configuration
Case drain portsL2, L4
Other ports
Customer interface threads
H1P 147/165 Operating Parameters
Size 147
3
147.2 cm
3
[8.98 in ]
441 l/min
[117 US gal/min]
2.34 N•m/bar
[1430 lbf•in/1000 psi]
2 2
0.027 kg•m [0.0199 slug•ft ]
96 kg [211 lb]
(without charge pump or auxiliary mounting flange)
3.0 l [0.8 US gal]
ISO 3019-1 Flange 152-4 (SAE D)
ISO 3019-1:
•
Outer Ø44 mm – 4 (SAE D, 13 teeth)
•
Outer Ø44 mm – 4 (SAE D, 27 teeth)
•
Conical keyed shaft end similar to ISO 3019-1 code 44-3, taper 1:8
ISO 3019-1:
•
Flange 82-2 Outer Ø16 mm – 4 (SAE A, 9 teeth)
•
Flange 82-2 Outer Ø19 mm – 4 (SAE A, 11 teeth)
•
Flange 101-2 Outer Ø22 mm – 4 (SAE B, 13 teeth)
•
Flange 101-2 Outer Ø25 mm – 4 (SAE B-B, 15 teeth)
•
Flange 127-4 Outer Ø32 mm – 4 (SAE C, 14 teeth)
•
Flange 152-4 Outer Ø44 mm – 4 (SAE D, 13 teeth)
5
1 ∕ -12 (SAE O-ring boss)
8
Ø31.5 mm - 450 bar split flange boss per ISO 6162, M12x1.75
5
ISO 11926-1 – 1 ∕ –12 (SAE O-ring boss)
16
SAE O-ring boss
Metric fasteners
11063347 | BC00000061en-US0701 | 5
on page 6.
Size 165
3
165.1 cm
3
[10.08 in ]
495 l/min
[131 US gal/min]
2.63 N•m/bar
[1605 lbf•in/1000 psi]
