Service Manual
Series 45 E Frame Open Circuit Pumps
Technical specifications

Hydraulic parameters

© Danfoss | September 2016
All manuals and user guides at all-guides.com

Inlet pressure

Minimum pressure, continuous = 0.8 bar absolute [6.7 inch Hg vac] (at reduced maximum pump speed)
Minimum pressure, cold start = 0.5 bar absolute [15.1 inch Hg vac]

Pressure compensator valve setting

Setting 100 and 130 cc
Minimum 100 bar [1450 psi]
Maximum 310 bar [4495 psi]

Case pressure

Maximum continuous: 0.5 bar [7 psi] Above inlet
Intermittent: 2 bar [29 psi] Cold start

Hydraulic fluid

Refer to Danfoss publication Fluids and Filtration BLN-9887 or 520L0463. For information on
biodegradable fluids refer to Biodegradable Hydraulic Fluids 520L0465. See
on page 20 for recommended fluid and filter change intervals.
(1)

Temperature range

Intermittent (cold start): - 40° C [- 40° F]
Continuous: 82° C [180° F]
(2)
Maximum : 104° C [220° F]
(1) Hydraulic fluid viscosity must be maintained within the prescribed limits.
(2) As measured at the hottest point in the system, e.g. drain line.

Fluid viscosity

Viscosity limits
Rating
ν continuous
ν intermittent

Filtration

Required cleanliness level: ISO 4406 Class 18/13 or better. Refer to Danfoss publications Fluids and
Filtration BLN-9887 or 520L0463 and Design Guidelines for Selecting and Maintaining the Required
Hydraulic Fluid Cleanliness 520L0465. See
fluid and filter change intervals.
minimum
maximum
minimum
maximum (cold start)
Fluid and Filter Maintenance
147 cc
260 bar [3770 psi]
Fluid and Filter Maintenance
mm2/s (cSt) [SUS]
9 [58]
110 [500]
6.4 [47]
1000 [4700]
on page 20 for recommended
AX00000024en-US0401 | 11
