Troubleshooting

Excessive noise and/or vibration

Item
Check fluid level in reservoir.
Check for air in system.
Check pump inlet pressure/vacuum.
Inspect shaft couplings.
Check shaft alignment.
Hydraulic fluid viscosity above acceptable limits.

Actuator response is sluggish

Item
Check external system relief valve setting.
Check PC and LS control setting.
Check LS control signal pressures.
Internal system leaks.
Hydraulic fluid viscosity above acceptable limits.
Check external system valving.
Check pump case pressure.
Check pump inlet pressure/vacuum.

System operating hot

Item
Check fluid level in reservoir.
Inspect heat exchanger. Check air flow and input
air temperature for the heat exchanger.
