8. Check and adjust the control setting. See Adjustments.
Control assembly
C104
3
/ inch
16
10.8 - 13.5 N•m
[8 - 10 lbf•ft]
C104A
C112
C105A
C106A
C106
3
/ inch
16
10.8 - 13.5 N•m
[8 - 10 lbf•ft]
C113
C115
C114
C118B
C118A
C118B
C118
LS control shown; parts C104 through C106 and C112 through C118 are not used on PC control
C103
3
/ inch
16
10.8 - 13.5 N•m
[8 - 10 lbf•ft]
C103A
C132
C105
3
/ inch
16
10.8 - 13.5 N•m
[8 - 10 lbf•ft]
C102
6 mm
7.5 - 10.8 N•m
[5.5 - 8 lbf•ft]
C200
C133
C300
4 mm
C135
5.4 - 7.5 N•m
[4 - 5.5 lbf•ft]
C134
C138A
C138
E101226
