Technical Specifications; H1 Pumps General Specification; H1 Pumps Physical Properties - Danfoss H1P 045 Service Manual

Service Manual
H1P 045/053/060/068 Axial Piston Single Pumps

Technical Specifications

H1 Pumps General Specification

H1 Pumps Physical Properties

Frame size 045/053
Mounting flange ISO 3019-1 flange 101-2 (SAE B)
Special bolt dia.
Input shaft outer diameter, ISO 3019-1, outer Ø22 mm -4 (SAE B, 13 teeth)
splines and tapered shafts ISO 3019-1, outer Ø25 mm -4 (SAE B-B, 15 teeth)
ISO 3019-1, outer Ø32 mm -4 (SAE B, 14 teeth)
Conical keyed shaft end similar to ISO 3019-1 code 25-3
taper 1:8
Auxiliary mounting flange Flange 82-2, outer Ø16 mm -4 (SAE A, 9 teeth)
with metric fasteners per Flange 82-2, outer Ø19 mm -4 (SAE A, 11 teeth)
ISO 3019-1, shaft outer Flange 101-2, outer Ø22 mm -4 (SAE B, 13 teeth)
diameter and splines Flange 101-2, outer Ø25 mm -4 (SAE B-B, 15 teeth)
Suction port
Main port configuration
Ø19.0 - 450 bar split flange boss per ISO 6162, M10x1.5
ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
Case drain ports L1, L2, L4
Other ports
Customer interface threads
24 | © Danfoss | June 2020
Axial piston closed circuit variable displacement pumps of cradle swash-plate design with clockwise or
counterclockwise direction of rotation.
Pipe connections
•
Main pressure ports: ISO split flange boss
•
Remaining ports: SAE straight thread O-ring boss
Recommended installation position
Pump installation position is discretionary, however the recommended control position is on the top or
at the side with the top position preferred. If the pump is installed with the control at the bottom,
flushing flow must be provided through port M14 located on the EDC, FNR and NFPE control.
Vertical input shaft installation is acceptable. If input shaft is at the top, 1 bar case pressure must be
maintained during operation. The housing must always be filled with hydraulic fluid. Recommended
mounting for a multiple pump stack is to arrange the highest power flow towards the input source.
Consult Danfoss for nonconformance to these guidelines.
Auxiliary cavity pressure
Auxiliary cavity pressure will be inlet pressure with internal charge pump or case pressure with external
charge supply. For reference see Operating Parameters. Please verify mating pump shaft seal capability.
060/068
ISO 3019-1 flange 127-4 (SAE C)
ISO 3019-1, outer Ø32 mm -4 (SAE C, 14 teeth)
ISO 3019-1, outer Ø35 mm -4 (SAE C, 21 teeth)
Flange 82-2, outer Ø16 mm -4 (SAE A, 9 teeth)
Flange 82-2, outer Ø19 mm -4 (SAE A, 11 teeth)
Flange 101-2, outer Ø22 mm -4 (SAE B, 13 teeth)
Flange 101-2, outer Ø25 mm -4 (SAE B-B, 15 teeth)
Flange 127-2, outer Ø32 mm -4 (SAE C, 14 teeth)
ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
Ø25.4 - 450 bar split flange boss per ISO 6162, M12x1.75
ISO 11926-1 – 1 1/16 -12 (SAE O-ring boss)
SAE O-ring boss. See installation drawings.
Metric fasteners
