Technical specifications

Technical specifications

H1P general specifications

Axial piston pump of cradle swashplate design with variable displacement
Design
Clockwise, counterclockwise
Direction of
rotation
Main pressure ports: ISO split flange boss
Pipe connections
Remaining ports: SAE straight thread O-ring boss
Pump installation position is discretionary, however the recommended control position is on the top or at the side, with the top
Recommended
position preferred. If the pump is installed with the control at the bottom, flushing flow must be provided through port M14
installation
located on the EDC, FNR and NFPE control. Vertical input shaft installation is acceptable. If input shaft is at the top 1 bar case
position
pressure must be maintained during operation.
The housing must always be filled with hydraulic fluid.
Recommended mounting for a multiple pump stack is to arrange the highest power flow towards the input source.
Consult Danfoss for nonconformance to these guidelines.
Will be inlet pressure with internal charge pump. For reference see operating parameter on next page. Will be case pressure with
Auxiliary cavity
external charge supply. Please verify mating pump shaft seal capability.
pressure

Technical data H1P 045/053

Feature
Displacement*
Flow at rated (continuous) speed*
Torque at maximum displacement (theoretical)*
Mass moment of inertia of rotating components
Mass [weight] dry (without charge pump or auxiliary mounting flange)
Oil volume
Mounting flange
Input shaft outer diameter, splines and tapered shafts
Auxiliary mounting flange with metric fasteners, shaft outer diameter and
splines
Suction port
Main port configuration
Case drain ports L2, L4 (SAE O-ring boss)
Other ports
Customer interface threads

Operating parameters H1P 045/053

Feature
Input speed Minimum for internal charge supply at minimum charge pressure.
Performance (pressure and displacement) may be limited due to limited
control pressure
H1 Axial Piston Pump Size 045/053, Single
For definitions of the following specifications, see Basic Information 11062168, Operating parameters.
11063344 • Rev HA • Mar 2014
Unit Size 045
cm³ [in³] 45.0 [2.75]
l/min [US gal/min] 153 [40]
N•m/bar [lbf•in/ 0.72 [437.7]
1000psi]
kg•m² [slug•ft²] 0.00465 [0.00343]
kg [lb] 41.0 [90.0]
liter [US gal] 1.3 [0.34]
ISO 3019-1 flange 101-2 (SAE B)
Special bolt diameter. See installation drawings.
ISO 3019-1, outer dia 22 mm - 4 (SAE B, 13 teeth)
ISO 3019-1, outer dia 25 mm - 4 (SAE B-B, 15 teeth)
ISO 3019-1, outer dia 32 mm - 4 (SAE-B, 14 teeth)
Conical keyed shaft end similar to ISO 3019-1 code 25-3, taper 1:8
ISO 3019-1, flange 82 - 2, outer dia 16 mm - 4 (SAE A, 9 teeth)
ISO 3019-1, flange 82 - 2, outer dia 19 mm - 4 (SAE A, 11 teeth)
ISO 3019-1, flange 101 - 2, outer dia 22 mm - 4 (SAE B, 13 teeth)
ISO 3019-1, flange 101 - 2, outer dia 25 mm - 4 (SAE B-B, 15 teeth)
ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
∅19.0 - 450 bar split flange boss per ISO 6162, M10x1.5
ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
ISO 11926-1 – 1 1/16 -12 (SAE O-ring boss)
SAE O-ring boss. See installation drawings at the back of this manual.
Metric fasteners
Unit
-1
min (rpm)
Size 053
53.8 [3.28]
183 [48]
0.86 [522.03]
0.00458 [0.00338]
Size 045 Size 053
500
5
