Page 2
Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose.
Page 3
Turning on or off the touch panel......... 19 Understanding the Christie touch panel interface and remote user interface... . 19 Turning on or off the light source.
Page 9
• CP4420-Xe Product documentation For installation, setup, and user information, see the product documentation available on the Christie Digital Systems USA Inc. website. Read all instructions before using or servicing this product. 1. Access the documentation from the Christie website: •...
Page 10
Introduction Safety precautions Learn about the safety precautions related to the Christie CineLife+ projector. This projector is intended for use in a cinema environment. General safety precautions Read all safety and warning guidelines before installing or operating the projector. Warning! If not avoided, the following could result in death or serious injury.
Page 11
• EXPLOSION HAZARD! Always wear protective safety clothing (gloves, jacket, face shield) approved by the manufacturer whenever the lamp door is open or when handling the lamp. Any local or federal specifications take precedence over Christie's protective clothing recommendations. •...
Page 13
"No direct exposure to beam shall be permitted". • The Christie Laser Projection System Installation Checklist must be fully completed after the installation and sent to lasercompliance@christiedigital.com. A copy can remain on-site. This checklist can be found as a separate document in the accessory box with the manual.
Page 35
Enables connection of MPEG-2 video formats. Enables connection of MPEG-2 MXF interop video formats. Enables connection of SMPTE-compatible 2D and 3D video formats Contact Christie Technical Support to learn which S2 and S4 IMB devices are compatible with Christie projectors. CineLife+ User Guide 020-103073-11 Rev.
Page 40
Media Block (IMB) devices. The input configurations supported are determined by the IMB device directly. Contact Christie Technical Support to learn which IMB devices provide HDMI source selection from the projector user interface. HDMI input selection directly from the IMB may also be possible using the IMB user interface. The input configurations supported are determined by the IMB make and model.
Page 46
Re-doing this calibration is required if the following is replaced: • Color sensor board Christie recommends re-doing this calibration if any of the following are replaced: • Light engine •...
Page 47
When the countdown ends, take x, y, and fL measurements using the spectroradiometer. Christie recommends taking meter readings from the center of the screen to obtain accurate screen measurements. c) Under Measured Values, using the numeric keypad record the associated spectroradiometer values for x, y, and fL.
Page 53
2. In the Alarm Triggers area, select Lamp Half Life. Lamp power ratings and warranty hours Determine the minimum and maximum lamp power ratings and warranty hours for each lamp. Find more information about Cinema lamp warranties on the Christie website: https://www.christiedigital.com/help-center/warranties/cinema-warranties/ CP2415-Xe...
Page 55
Learn how to create new user accounts, modify the properties of those accounts, and remove the accounts. A user account is a set of credentials consisting of both a username and password allowing access to projector settings. Default user access permissions The following table lists the Christie touch panel access permissions. Permission Description installer Can define Ethernet settings (IP network address), restore backup files, and upgrade the system software.
Page 68
3D encoding. • 3D Line Interleaved—The left-eye and right-eye data are sent on alternating lines. 3D Sync Input Mode is not required when using the Christie IMB. For GDC IMB devices, the recommended setting is 3D Line Interleaved. ™...
Page 79
Warp files provide image configuration information to support projection in environments with multiple projectors and complex screen shapes. Warp files are created using an automated process through Christie Mystique. For more information on using Christie Mystique in a cinema environment, see the Mystique User Guide—Cinema Edition (P/N: 020-001240-XX). CineLife+ User Guide 020-103073-11 Rev.
Page 80
Adjusting the image size and position 1. Using Christie Mystique, create the required warp file. 2. Using Mystique, upload the warp file to the projector. 3. On the projector touch panel, navigate to Image Settings > Warp File Setup. 4. To activate the warp file, find the file name in the Warp File list and select Activate.
Page 81
2. If the keystone effect is severe, unevenly adjust the feet to compensate for projector tilt. Christie recommends using the lens offset to align the center of the image to the center of the screen before correcting the keystone effect.
Page 90
You can also create a custom macro that uses the fire alarm trigger or edit the default fire alarm macro to perform other actions as needed. Christie ACT actions The following built-in commands are available for Christie ACT. Command Description Buzzer Activates the buzzer for the specified time (in milliseconds).
Page 91
(www.integpg.com). Port 9200 is the default Ethernet port for sending automation commands to the JNIOR. • The jnior login must be disabled and the jnior username and password removed in the Christie software to allow the cues to pass over the network. •...
Page 98
An upgrade package is used to upgrade the projector software to the latest version. The upgrade package is installed from a USB key or from the projector's ftpuser directory. To obtain the upgrade package, contact Christie Technical support. 1. Power on the projector and place it in Standby mode.
