Specifications VLT® AutomationDrive FC 302
9.8.4 E4h Exterior Dimensions
3X 13 (0.5)
1578
9 9
1537
(62.1)
(60.5)
1348
(53.1)
A
13 (0.5)
15 (0.6)
10 (0.4)
30
10 (0.4)
(1.2)
604
A
(23.8)
Illustration 9.14 Front View of E4h
