Electrical Installation
5.7.3 E3h Terminal Dimensions
5 5
6X 148 (5.8)
1
90 (3.5)
50 (2.0)
1 Mains terminals
2 Brake or regeneration terminals
Illustration 5.10 E3h Terminal Dimensions (Front View)
34
0 (0.0)
Danfoss A/S © 04/2018 All rights reserved.
VLT® AutomationDrive FC 302
3 Motor terminals
4 Ground terminals, M8 and M10 nuts
2
256 (10.1)
3
4
33 (1.3)
