Mechanical Installation
1
4 4
2
3
4
1 Load share/regeneration terminals (optional)
2 Bottom panel
3 Terminal cover
4 Grommet access hole for control wiring
5 Track guide
Illustration 4.8 Assembling the Gland Plate and Terminal Cover
18
VLT® AutomationDrive FC 302
6 Slotted drive bracket
7 Plastic gland plate (installed)
8 Fastener point
9 Keyhole opening
– –
