Locking the display panel

The SET key can be programmed to act as a shortcut to access the "LOCK PANEL" function.
To access this information go to the "CONFIGURATION" menu and select the "GENERAL" menu.
You can access the "CONFIGURATION" menu by:
• Holding down the SET key
• By selecting the icon from the process setting page.
• Select the "GENERAL" menu.
Select the "SET BUTTON" and "LOCK PANEL" option.
MAIN MENU MAIN SUB-MENU
GENERAL SET BUTTON
Now, from the "WELDING" page, push the SET
The icon appears on the display, meaning that the display is locked, and the operator cannot change any welding parameter.
Push the SET key again to exit this functi8on, and the display panel will be unlocked.
for 5 seconds.
PARAMETERS /
HIGH - LOW LIMIT
GAS FLOW TEST
LOCK PANEL
LOAD JOB
key to access the "LOCK PANEL" function quickly.
DEFAULT
NOTE
VALUE
X
Set the chosen option for the SET button
Push the SET key
option chosen
42
a second time to exit the
