JOB - Viewing the parameters set for a saved program

Proceed as follows:
1. Load the program (JOB) saved, as described in the previous chapter.
J-01 JOB 01
80
2.4
Ø
2.
Push the knob to enter the SET page. A graphic of the welding process for the JOB loaded will be displayed.
80
80
A
IGNITION
Ø
2.4mm
0.25 s 0.0 s 80A
MAIN CURRENT
3. By rotating the knob you can view all the parameters of the JOB loaded.
4. By pushing the knob on a parameter of the JOB loaded, you can edit its value.
NOTE: If the parameters set are changed, you automatically exit the JOB loaded (the
JOB
v
12.0
A
JOB
A
0.0 s 6.0 s
symbol disappears from the display).
JOB
