Locking / unlocking the display panel using a password

A password can be set for unlocking the display panel.
To access this information go to the "CONFIGURATION" menu and select the "PANEL LOCK" menu.
You can access the "CONFIGURATION" menu by:
• Holding down the SET key
• By selecting the icon from the process setting page.
• Select the "UPANEL LOCK" menu.
Select the "PANEL LOCK" option.
MAIN MENU MAIN SUB-MENU
LOCK PANEL
PANEL LOCK
SET UNLOCK CODE
Set the required password for unlocking, and activate the "LOCK PANEL" function.
The icon appears on the display, meaning that the display is locked, and the operator cannot change any welding parameter.
Push the SET key again to exit this functi8on, and the display panel will be unlocked.
for 5 seconds.
PARAMETERS /
HIGH - LOW LIMIT
NO
YES
DEFAULT
NOTE
VALUE
X
Locks the panel. To release, hold the SET key
down for 5 seconds
Used to set a personal panel release code
