• MMA
- Option to choose between the MMA DC and MMA AC electrode welding.
- The VRD (Voltage Reduction Device) can be activated, which reduces voltages to below 12 V, which means
that the welding machine can be used in ambient conditions in which there is a high electrical risk, thereby
providing maximum operator safety.
- "Arc Force" adjustable to select the best dynamic characteristics for the welding arc.
- "Hot Start" adjustable to improve ignition with particularly difficult electrodes.
- Anti-sticking function to avoid the electrodes sticking.
MATRIX X220 AC/DC
The PFC device makes the wave form of the current absorbed sinusoidal, which results in no harmonic disturbance on the mains and
optimisation of absorption, which allows you to use the generator's full power with a 16 A fuse, as well as ensuring greater protection of
the welding machine against fluctuations in the power supply voltage.

Usage limits (IEC 60974-1)

The use of a welder is typically discontinuous, in that it is made up of effective work periods (welding) and rest periods (for the positio-
ning of parts, the replacement of wire and underflushing operations etc.
This welder is dimensioned to supply a I
regulations in force establish the total usage time to be 10 minutes.
The work cycle is considered to be X% of this period of time. If the permitted work cycle time is exceeded, an overheat cut-off occurs to
protect the components around the welder from dangerous overheating.
Tripping of the trip switch is indicated by the
After several minutes the overheat cut-off rearms automatically and the welder is ready for use again.

Technical data

The general technical data of the system are summarized in table 1.
Model
Power supply 50/60 Hz
Power supply: Z
max
Input power @ I Max
2
@ 100%)
Delayed fuse (I
2
Power factor / cosφ
Efficiency degree
Input power at IDLE state
Open circuit voltage
Current range
Duty cycle @ 100% (40°C)
Duty cycle @ 60% (40°C)
Duty cycle @ X% (40°C)
Usable electrodes
Standards
Protection class
Insulation class
Dimensions
Weight
IMPORTANT:
These systems, tested in accordance with the requirements of the EN/IEC 61000-3-3 standard, satisfy the requirements laid down by the EN/
IEC 61000-3-11 standard.
MATRIX X220 AC/DC
(*) This equipment meets the requirements laid down in the EN/IEC 61000-3-12 standard on harmonic currents.
MATRIX X300 AC/DC
This equipment complies with EN/IEC 61000-3-12 provided that the maximum permissible system impedance Z
at the interface point between the user's supply and the public system. It is the responsibility of the installer or user of the equipment to ensure,
by consultation with the distribution network operator if necessary, that the equipment is connected only to a supply with maximum permissible
system impedance Z less than or equal to 0,092.
max
max nominal current in complete safety for a period of work of X% of the total usage time. The
2
symbol on the display (see the manual for the XVision control panel).
MATRIX X220 AC/DC
TIG
V 1~ 230 ±20%
Ω (*)
kVA 6,5
A 16
0,99 / 0,99
η 0,80
W 20
V 85
1÷220 3÷220
A
(TIG DC) (TIG AC)
A 140
A 180
A 220 (30%)
mm 1,2÷2,4
IEC 60974-1 • IEC 60974-3 • IEC 60974-10
IP 23 S
F
mm 530 - 410 - 215
kg 19.8
MMA
7,0
1÷300
10÷180
(TIG DC)
120
150
180 (30%) 300 (35%)
1,6÷4,0
IEC 60974-1 • IEC 60974-3 • IEC 60974-10
4
MATRIX X300 AC/DC
TIG MMA
3~ 400 ±20%
0,092
9,6
10
0,95 / 0,99
0,82
15
85
3÷300
10÷250
(TIG AC)
210 190
250 220
250 (40%)
1,2÷4,0 1,6÷5,0
IP 23 S
F
530 - 410 - 215
21.4
is less than or equal to 0,092
max
Table 1
