Hardware test menu

The hardware test menu allows you to test functioning of the gas solenoid valve, the fan, and the cooling unit.
To access this information go to the "CONFIGURATION" menu and select the "HW TEST" menu.
You can access the "CONFIGURATION" menu by:
• Holding down the SET key
• By selecting the icon from the process setting page.
• Select the "HW TEST" menu.
CONFIGURATION
ERROR PAGE
PANEL LOCK
USB SAVE RESTORE DATA
DIAGNOSTIC
HW TEST
MAIN MENU MAIN SUB-MENU
GAS
HW TEST FAN
COOLING
for 5 seconds.
PARAMETERS /
HIGH - LOW LIMIT
OFF
ON
OFF
ON
OFF
ON
DEFAULT
NOTE
VALUE
X
Service centre test.
Activates / Deactivates the gas solenoid valve
X
Service centre test.
Activates / Deactivates the fan
X
Service centre test.
Activates / Deactivates the cooling system
