JOB - Salving and uploading saved programs to a USB stick

Saved programs can be saved on a USB stick so that they can be moved from one welding machine to another, or recovered if the ma-
chine is "reset".
NOTE: Use a new, dedicated "FAT32" USB stick for this purpose.
To access this information go to the "CONFIGURATION" menu and select the "USB SAVE RESTORE DATA" menu.
You can access the "CONFIGURATION" menu by:
• Holding down the SET key
• By selecting the icon from the process setting page.
• Select the "USB SAVE RESTORE DATA" menu.
CONFIGURATION
WELDING
INFORMATION
ERROR PAGE
PANEL LOCK
USB SAVE RESTORE DATA
• Insert a new "FAT32" USB stick into the USB socket on the welding machine's front panel.
• Select the "USB SAVE JOBS" or "USB LOAD JOBS" sub-menu.
MAIN MENU MAIN SUB-MENU
USB SAVE JOBS
USB SAVE
SETTINGS
USB SAVE
RESTORE DATA
USB LOAD JOBS
USB LOAD
SETTINGS
• Follow the guided procedure indicated on the display.

JOB - Selecting a JOB using the TIG torch's "UP / DOWN" keys (sequences)

When a TIG "UP / DOWN" torch is installed, you can select JOBS in a sequence of JOBS, using the torch's UP(+) / DOWN (-) keys.
To create a JOB sequence, leave a memory slot open before and after the JOB group that you want to make into a sequence.
SEQUENCE 1
MAN
J-01 J-02
Once the required sequences have been created, select and load one of the JOBS in the required sequence (e.g. J-05).
Use the torch's UP(+) / DOWN (-) keys to scroll the JOBS in the sequence (J-05 → J-06 → J-07 → J-05).
Push the torch button to start the welding process using the JOB parameters shown on the display.
Since JOBS can be copied, moved, and deleted, from one position to another, the groups of work sequences required can easily be
defined.
for 5 seconds.
PARAMETERS /
HIGH - LOW LIMIT
JOB not
saved
J-03 J-05
DEFAULT
NOTE
VALUE
Activates the procedure for saving JOBS on a new
"FAT32" USB stick, set aside for this purpose
Activates the procedure for saving the settings
on a new "FAT32" USB stick, set aside for this
purpose
Activates the procedure for uploading JOBS to a
new "FAT32" USB stick, set aside for this purpose
Activates the procedure for uploading the settings
to a new "FAT32" USB stick, set aside for this
purpose
SEQUENCE 2 JOB not
saved
J-06 J-07
37
SEQUENCE 3
J-09 J-10 J-11
