FC 300 Operating Instructions
Accessory Bag 11-22 kW
Mechanical Installation
Basic Enclosures
FC 300 IP20 - see table for
mechanical dimensions
How to Install
There is only one relay connector for FC 301. (11-22 kW)
Mechanical dimensions of the IP
21/IP 4x/ TYPE 1 enclosure kit (≤
7.5 kW)
MG.33.A5.02 - VLT is a registered Danfoss trademark
Mechanical dimensions of the IP
21/IP 4x/ TYPE 1/IP55/TYPE 12
(11-22 kW)
