FC 300 Operating Instructions

Basic Parameters

0-01 Language
Option:
*
English (ENGLISH)
German (DEUTSCH)
French (FRANCAIS)
Danish (DANSK)
Spanish (ESPANOL)
Italian (ITALIANO)
Chinese (CHINESE)
Finnish (FINNISH)
English US (ENGLISH US)
Greek (GREEK)
Portuguese (PORTUGUESE)
Slovenian (SLOVENIAN)
Korean (KOREAN)
Japanese (JAPANESE)
Turkish (TURKISH)
Traditional Chinese
Bulgarian
Serbian
Romanian (ROMANIAN)
Hungarian (HUNGARIAN)
Czech
Polish (POLISH)
Russian
Thai
Bahasa Indonesian (BAHASA
INDONESIAN)
Function:
Defines the language to be used in display.
The frequency converter can be delivered with
4 various language packages. English and
German are included in all packages. English
cannot be erased or manipulated.
1-20 Motor Power [kW]
Range:
0.37-7.5 kW
Function:
The value should equal the nameplate data on the
connected motor. The default value corresponds
to the nominal rated output of the unit.
1-22 Motor Voltage
Range:
200-600 V
default setting display text
* ( )
How to Programme
The value should equal the nameplate data on the
connected motor. The default value corresponds
to the nominal rated output of the unit.
[0]
[1]
[2]
*
[3]
[4]
[5]
[10]
[20]
Select the stated value from the motor name plate.
[22]
Alternatively, set the value for motor frequency to be
[27]
infinitely variable. If a value different from 50 Hz or
[28]
60 Hz is selected, it is necessary to correct par. 1-50
[36]
to 1-53. For 87 Hz operation with 230/400 V motors,
[39]
set the nameplate data for 230 V/50 Hz. Adapt par.
[40]
4-13 Motor Speed High Limit [RPM) and par. 3-03
[41]
Maximum Reference to the 87 Hz application.
[42]
[43]
[44]
[45]
[46]
[47]
The value should equal the nameplate data on
[48]
[49] the connected motor. Data is used for calculating
torque, motor protection etc.
[50]
[51]
The value should equal the name plate data
on the connected motor. The data is used for
calculating motor compensations.
*
[M-TYPE]
If the AMA function is used, the frequency
converter automatically sets the necessary motor
parameters (par. 1-30 to par. 1-35) with the
motor stationary. AMA ensures optimum use of the
motor. For the best adaptation of the frequency
[M-TYPE]
converter, run AMA on a cold motor.
Select Enable complete AMA, if the frequency
converter is to carry out AMA of the stator
value for use in communication via serial communication port
[ ]
MG.33.A5.02 - VLT is a registered Danfoss trademark
Function:
1-23 Motor Frequency
Option:
50 Hz (50 HZ)
60 Hz (60 HZ)
Min - Max motor frequency: 20 - 300 Hz
Function:
1-24 Motor Current
Range:
Motor type dependent.
Function:
1-25 Motor Nominal Speed
Range:
100 - 60000 RPM
Function:
1-29 Automatic Motor Adaptation (AMA)
Option:
OFF
Enable complete AMA
Enable reduced AMA
Function:
[50]
[60]
*
RPM
[0]
[1]
[2]
45
