FC 300 Operating Instructions
Mechanical dimensions
Height
Height of back
A
plate
Distance
between a
mounting holes
Width
Width of back
B
plate
Distance
between b
mounting holes
Depth
Depth without
C
option A/B
With option A/B
Without option
D
A/B
With option A/B D
Screw holes
c
d
e
f
Max weight
Mechanical mounting
Drill holes in accordance with the measurements given.
1.
You must provide screws suitable for the surface on which you want to mount
2.
the FC 300. Retighten all four screws.
FC 300 IP20 allows side-by-side installation. Because of the need for cooling, there must be a
minimum of 100 mm free air passage above and below the FC 300.
The back wall must always be solid.
14
How to Install
Frame size A2
0.25-2.2 kW (200-240 V)
0.37-4.0 kW (380-500 V)
IP20 IP21/Type 1
268 mm 375 mm 268 mm
257 mm 350 mm 257 mm
90 mm 90 mm
70 mm 70 mm 110 mm
205 mm 205 mm 205 mm
220 mm 220 mm
207 mm
222 mm
8.0 mm 8.0 mm 8.0 mm
ø11 mm ø11 mm ø11 mm
ø5.5 mm ø5.5 mm ø5.5 mm
9 mm 9 mm
4.9 kg 5.3 kg
MG.33.A5.02 - VLT is a registered Danfoss trademark
Frame size A5
Frame size A3
0.25-3.7 kW
3.0-3.7 kW (200-240 V)
(200-500 V)
5.5-7.5 kW (380-500 V)
0.37-7.5 kW
0.75-7.5 kW (550-600 V)
(380-500 V)
IP20 IP21/Type 1
375 mm 420 mm
350 mm 402 mm
130 mm 242 mm
110 mm 215 mm
205 mm 195 mm
195 mm
8.0 mm 8.25 mm
ø11 mm ø12 mm
ø5.5 mm ø6.5 mm
9 mm 9 mm
6.6 kg 7.0 kg
Frame size B1 Frame size B2
11-15 kW 18.5-22 kW
(380-500 V) (380-500 V)
IP55 IP21
480 mm 650 mm
454 mm 624 mm
242 mm 242 mm
210 mm 210 mm
260 mm 260 mm
260 mm
12 mm 12 mm
ø19 mm ø19 mm
ø9 mm ø9 mm
9 mm 9 mm
23 kg
IP21
9 mm
27 kg
