FC 300 Operating Instructions
7-** Controllers
Par.
Parameter description
No.
#
7-0* Speed PID Ctrl.
7-00
Speed PID Feedback Source
7-02
Speed PID Proportional Gain
7-03
Speed PID Integral Time
7-04
Speed PID Differentiation Time
7-05
Speed PID Diff. Gain Limit
7-06
Speed PID Lowpass Filter Time
7-2* Process Ctrl. Feedb
7-20
Process CL Feedback 1 Resource
7-22
Process CL Feedback 2 Resource
7-3* Process PID Ctrl.
7-30
Process PID Normal/ Inverse Control
7-31
Process PID Anti Windup
7-32
Process PID Start Speed
7-33
Process PID Proportional Gain
7-34
Process PID Integral Time
7-35
Process PID Differentiation Time
7-36
Process PID Diff. Gain Limit
7-38
Process PID Feed Forward Factor
7-39
On Reference Bandwidth
8-** Comm. and Options
Par.
Parameter description
No.
#
8-0* General Settings
8-01
Control Site
8-02
Control Word Source
8-03
Control Word Timeout Time
8-04
Control Word Timeout Function
8-05
End-of-Timeout Function
8-06
Reset Control Word Timeout
8-07
Diagnosis Trigger
8-1* Ctrl. Word Settings
8-10
Control Word Profile
8-13
Configurable Status Word STW
8-3* FC Port Settings
8-30
Protocol
8-31
Address
8-32
FC Port Baud Rate
8-35
Minimum Response Delay
8-36
Max Response Delay
8-37
Max Inter-Char Delay
8-4* FC MC protocol set
8-40
Telegram selection
8-5* Digital/Bus
8-50
Coasting Select
8-51
Quick Stop Select
8-52
DC Brake Select
8-53
Start Select
8-54
Reversing Select
8-55
Set-up Select
8-56
Preset Reference Select
8-9* Bus Jog
8-90
Bus Jog 1 Speed
8-91
Bus Jog 2 Speed
default setting
display text
*
( )
How to Programme
Default value
null
ExpressionLimit
ExpressionLimit
ExpressionLimit
5.0 N/A
10.0 ms
[0] No function
[0] No function
[0] Normal
[1] On
0 RPM
0.01 N/A
10000.00 s
0.00 s
5.0 N/A
0 %
5 %
Default value
[0] Digital and ctrl.word
null
1.0 s
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
[0] FC profile
[1] Profile Default
[0] FC
1 N/A
[2] 9600 Baud
10 ms
5000 ms
25 ms
[1] Standard telegram 1
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
100 RPM
200 RPM
value for use in communication via serial communication port
[ ]
MG.33.A5.02 - VLT is a registered Danfoss trademark
4-set-up
FC 300
Change
series
during
operation
All set-ups
FALSE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
4-set-up
FC 300
Change
series
during
operation
All set-ups
TRUE
All set-ups
TRUE
1 set-up
TRUE
1 set-up
TRUE
1 set-up
TRUE
All set-ups
TRUE
2 set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
1 set-up
TRUE
1 set-up
TRUE
1 set-up
TRUE
All set-ups
TRUE
1 set-up
TRUE
1 set-up
TRUE
2 set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
Conver-
Type
sion index
-
Uint8
-3
Uint16
-4
Uint32
-4
Uint16
-1
Uint16
-4
Uint16
-
Uint8
-
Uint8
-
Uint8
-
Uint8
67
Uint16
-2
Uint16
-2
Uint32
-2
Uint16
-1
Uint16
0
Uint16
0
Uint8
Conver-
Type
sion index
-
Uint8
-
Uint8
-1
Uint32
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
0
Uint8
-
Uint8
-3
Uint16
-3
Uint16
-3
Uint16
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
67
Uint16
67
Uint16
55
