Danfoss FC 300 Operating Instructions Manual page 60

FC 300 Operating Instructions
16-** Data Readouts
Par. Parameter description
No.
#
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
16-16 Torque
16-17 Speed [RPM]
16-18 Motor Thermal
16-20 Motor Angle
16-3* Drive Status
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-5* Ref. & Feedb.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-74 Prec. Stop Counter
16-75 Analog In X30/11
16-76 Analog In X30/12
16-77 Analog Out X30/8 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-92 Warning Word
16-94 Ext. Status Word
* default setting ( ) display text
60
How to Programme
Default value
0 N/A
0.000 ReferenceFeed-
backUnit
0.0 %
0 N/A
0.00 %
0.00 kW
0.00 hp
0.0 V
0.0 Hz
0.00 A
0.00 %
0.0 Nm
0 RPM
0 %
0 N/A
0 V
0.000 kW
0.000 kW
0 °C
0 %
ExpressionLimit
ExpressionLimit
0 N/A
0 °C
[0] No
0.0 N/A
0.0 N/A
0.000 ReferenceFeed-
backUnit
0.00 N/A
0 N/A
[0] Current
0.000 N/A
[0] Current
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
[ ] value for use in communication via serial communication port
MG.33.A5.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Conver- Type
sion index
0 V2
-3 Int32
-1 Int16
0 V2
-2 N2
1 Int32
-2 Int32
-1 Uint16
-1 Uint16
-2 Int32
-2 N2
-1 Int16
67 Int32
0 Uint8
0 Uint16
0 Uint16
0 Uint32
0 Uint32
100 Uint8
0 Uint8
-2 Uint32
-2 Uint32
0 Uint8
100 Uint8
- Uint8
-1 Int16
-1 Int16
-3 Int32
-2 Int16
0 Uint16
- Uint8
-3 Int32
- Uint8
-3 Int32
-3 Int16
0 Int16
0 Int32
0 Int32
0 Int32
0 Int32
0 Int16
0 Int32
0 Int32
0 Uint32
-3 Int32
-3 Int32
-3 Int16
0 V2
0 N2
0 V2
0 V2
0 N2
0 Uint32
0 Uint32
0 Uint32
