FC 300 Operating Instructions
Additional Connections
24 V Back-up Option
Terminal numbers:
Terminal 35: - external 24 V DC supply.
Terminal 36: + external 24 V DC supply.
Attach 24 V DC cable to the 24 V plug connector.
1.
2.
Insert plug connector into terminals
labellled 35, 36.
28
How to Install
Connection to 24 V back-up supply (≤ 7.5 kW).
Connection to 24 V back-up supply (11-22 kW).
MG.33.A5.02 - VLT is a registered Danfoss trademark
