Parts List - Analog Devices DC2575A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C4
5 1 C5
6 1 C6
7 2 C7, C8
8 1 C10
9 2 C12, C32
10 2 C14, C20
11 2 D1, D2
12 2 M1, M2
13 2 M3, M4
14 1 L1
15 1 Q1
16 1 R1
17 1 R2
18 1 R3
19 1 R4
20 1 R5
21 1 R6
22 1 R7
23 1 R8
24 1 U1
Optional Low EMI Electrical Components
1 3 C34, C35, C36
2 3 C37, C38, C44
3 2 C40, C41
4 2 D3, D4
5 2 FB1, FB2
6 2 FB3, FB4
7 2 R15, R17
8 2 R32, R33
PART DESCRIPTION
CAP ., 1µF, X7S, 100V, 10%, 0805
CAP ., 4.7µF, X5R, 10V, 10%, 0402
CAP ., 0.47µF, X5R, 16V, 10%, 0402
CAP ., 3300pF, X7R, 16V, 10%, 0402
CAP ., 0.022µF, X7R, 25V, 10%, 0402, AEC-Q200, NO SUBS.
ALLOWED
CAP ., 1µF, X7R, 25V, 10%, 0603
CAP ., 0.1µF, X7R, 25V, 10%, 0402, AEC-Q200, NO SUBS.
ALLOWED
CAP ., 22µF, ALUM., 63V, 20%, SMD 6.3mm × 7.7mm, D8, AEC-
Q200
CAP ., 4.7µF, X7S, 100V, 10%, 1210, AEC-Q200, NO SUBS.
ALLOWED
CAP ., 10µF, X5R, 25V, 20%, 1210, AEC-Q200, NO SUBS. ALLOWED MURATA, GCM32ER71E106KA57L
DIODE, SCHOTTKY, 100V, 250mA, SOD323F , AEC-Q101
XSTR., MOSFET, N-CH, 60V, 22A, LFPAK33-8, AEC-Q101
XSTR., MOSFET, N-CH, 40V, 40A, PG-TSDSON-8, AEC-Q101
IND., 2.2µH, PWR, 20%, 9.2A, 14.5mΩ, 5.48mm × 5.28mm,
XAL5030, AEC-Q200
XSTR., MOSFET, P-CH, 30V, 4.2A, SOT23-3 (TO-236AB), AEC-Q101 NEXPERIA, PMV50EPEA
RES.,0.006Ω,1%,1.5W,1206, LONG-SIDE TERM.,KRL3216E,
SENSE, AEC-Q200
RES.,0.056Ω, 1%, 1/2W, 1206, SHORT-SIDE TERM., RL1632,
SENSE
RES., 59.0kΩ, 1%, 1/16W, 0402, AEC-Q200
RES.,4.7kΩ, 5%, 1/16W,0402
RES.,1MΩ, 1%, 1/10W, 0603
RES., 54.9kΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 383kΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 165kΩ, 1%, 1/16W, 0402, AEC-Q200
IC,4-Switch Buck-Boost LED CTRLR,TSSOP-28FE
CAP .,0.1uF ,X5R,100V,10%,0402,NO SUBS. ALLOWED
CAP .,0.1uF ,X7R,25V,10%,0402,AEC-Q200, NO SUBS. ALLOWED
CAP .,4.7uF ,X7S,100V,10%,1210,AEC-Q200, NO SUBS. ALLOWED
DIODE,SCHOTTKY,20V,1A,SOD523-2
IND.,220 OHMS,BEAD,
FERRITE,25%,3A,40mOHMS,0805,AEC-Q200
IND.,1k OHM,BEAD,
FERRITE,25%,1.5A,150mOHMS,0805,AEC-Q200
RES.,10 OHMS,5%,1/16W,0402
RES.,5.1,OHMS,1%,1/16W,0402,AEC-Q200
DEMO MANUAL DC2575A
MANUFACTURER/PART NUMBER
MURATA, GRJ21BC72A105KE11L
TDK, C1005X5R1A475K050BC
TAIYO YUDEN, EMK105ABJ474KV-F
MURATA, GRM15XR71C332KA86D
MURATA, GCM155R71E223KA55D
MURATA, GRM188R71E105KA12D
TDK, CGA2B3X7R1E104K050BB
PANASONIC, EEHZC1J220XP
MURATA, GCM32DC72A475KE02L
NEXPERIA, BAT46WJ,115
NEXPERIA, BUK9M42-60E
INFINEON, IPZ40N04S5L-7R4
COILCRAFT, XAL5030-222MEC
SUSUMU, KRL3216E-C-R006-F-T1
SUSUMU, RL1632R-R056-F
VISHAY, CRCW040259K0FKED
NIC, NRC04J472TRF
PANASONIC, ERJ3EKF1004V
VISHAY, CRCW040254K9FKED
VISHAY, CRCW0402383KFKED
VISHAY, CRCW0402165KFKED
ANALOG DEVICES, LT8391AIFE#PBF
MURATA, GRM155R62A104KE14D
TDK, CGA2B3X7R1E104K050BB
MURATA, GCM32DC72A475KE02L
NEXPERIA, PMEG2010AEB,115
TDK, MPZ2012S221ATD25
TDK, MPZ2012S102ATD25
VISHAY, CRCW040210R0JNED
VISHAY, CRCW04025R10FKED
Rev. A
7
