Example Input Schematic - adept technology IO Blox User Manual

Chapter 3 - General Operation

Example Input Schematic

User-Supplied Equipment
NPN
Sensor (Sink)
+V
Out
G
PNP
Sensor (Source)
+V
Out
G
+12VDC
PLC 1 (Source)
12V
PLC 2 (Sink)
24V
Figure 3-3. Typical User Wiring for Input Signals
30
Limit Switch Source
Limit Switch Sink
+
+24VDC
–
User
Supply
Adept IO Blox User's Guide, Rev B
Adept-Supplied Equipment
DIGITAL INPUTS
I1 (UPR)
3.9K
PS2805-4
I1 (LWR)
A (UPR)
B (LWR)
I2 (UPR)
3.9K
PS2805-4
I2 (LWR)
I3 (UPR)
3.9K
PS2805-4
I3 (LWR)
A (UPR)
B (LWR)
I4 (UPR)
3.9K
PS2805-4
I4 (LWR)
I5 (UPR)
3.9K
PS2805-4
I5 (LWR)
A (UPR)
B (LWR)
I6 (UPR)
3.9K
PS2805-4
I6 (LWR)
I7 (UPR)
3.9K
PS2805-4
I7 (LWR)
A (UPR)
B (LWR)
I8 (UPR)
3.9K
PS2805-4
I8 (LWR)
3.3K
5VD
DI_1
D
