Bill of material

The complete bill of material can be downloaded (a customer login is required) from the Download section on
the homepage of Infineon's website.
Table 3 BOM of the most important/critical parts of the evaluation board
Quantity Ref Designator
C1, C4, C5, C7, C9,
7
C20, C25
1 C2
C3, C6, C8, C28,
7
C37, C40, C56
2 C10, C12
2 C11, C13
C14, C15, C16, C17,
12 C18, C19, C22, C26,
C29, C30, C52, C53
2 C21, C27
1 C23
1 C24
2 C31, C32
4 C33, C34, C35, C43
1 C36
2 C38, C39
1 C41
1 C42
1 C44
1 C45
1 C46
1 C47
Description
Chip Monolithic Ceramic Capacitor
Chip Monolithic Ceramic Capacitor
Chip Monolithic Ceramic Capacitor, CAP /
CERA / 100nF/ 50V/ 10%/ X7R (EIA)/ -
55℃ to 125℃/ 603(1608)/ SMD
CAP / FILM / 1uF / 630V / 10% / MKT
(Metallized Polyester) / -40℃ to 105℃ /
22.50mm C X 0.80mm W 26.00mm L X
11.00mm T X 20.50mm H / THT / -
CAP / CERA / 2.2nF / 1kV / 20% / Y5U
(EIA) / -40℃ to 125℃ / 5.00mm C X
0.60mm W 9.00mm L X 5.00mm T X
13.00mm H / THT / -
Chip Monolithic Ceramic Capacitor, CAP /
CERA / 1nF / 25V / 5% / C0G (EIA) / NP0 /
-55℃ to 125℃ / 0603(1608) / SMD
Chip Monolithic Ceramic Capacitor
MLCC Chip Capacitor, SMD
Chip Monolithic Ceramic Capacitor
CAP / ELCO / 470uF / 400V / 20% /
Aluminiumelectrolytic / -25℃ to 85℃/
10.00mm C X 1.50mm W 35.00mm Dia X
37.00mm H / - / -
Chip Monolithic Ceramic Capacitor, CAP /
CERA / 10nF / 50V / 10% / X7R (EIA) / -
55℃ to 125℃ / 0603 / SMD / -
CAP / FILM / 470nF / 630V / 5% / MKP
(Metallized Polypropylene) / -40℃ to 105℃
/ 22.50mm C X 0.80mm W 26.00mm L X
9.00mm T X 19.00mm H / THT / -
CAP / ELCO / 330uF / 25V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃ /
3.50mm C X 0.60mm W 8.00mm Dia X
13.00mm H / THT / -
CAP / CERA / 100nF / 630V / 10% / X7R
(EIA) / -55℃ to 125℃ / 1812 / SMD / -
CAP / CERA / 1nF / 630V / 10% / X7R
(EIA) / -55℃ to 125℃ / 1206(3216) / SMD
CAP / CERA / 100nF / 50V / 10% / X7R
(EIA) / -55℃ to 125℃ / 0603 / SMD / -
CAP / ELCO / 220uF / 16V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃ /
2.50mm C X 0.50mm W 6.30mm Dia X
12.50mm H / THT / -
CAP / CERA / 10uF / 16V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0805(2012) / SMD
CAP / ELCO / 100uF / 16V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃ /
2.00mm C X 0.50mm W 5.00mm Dia X
12.50mm H / THT / -
18
Manufacturer Manufacturer P/N
MuRata GRM31CR71E106MA12
MuRata GCM188R71E472JA37
GRM188R61E104KA01,
MuRata, AVX
06035C104K4Z2A
Wurth Elektronik 890324026027CS
Vishay VY2222M35Y5US6TV5
GRM188R71E102JA01,
MuRata
GRM1885C1E102JA01
MuRata GRM1885C1H220JA01
TDK Corporation C3216X5R1E226M160AB
MuRata GRM188R71H471KA01
Wurth Elektronik 861221386021'
GRM188R71C103KA01,
MuRata, AVX
06035C103K4Z2A
Wurth Elektronik 890303326009CS
Wurth Elektronik 860010474012'
Wurth Elektronik 8.85342E+11
MuRata GRM31BR72J102KW01
AVX 06035C104KAT2A
Wurth Elektronik 860010373010'
MuRata GRM219R61C106KA73
Wurth Elektronik 860010473007'
