EVAL-M7-D112T user guide
iMOTION™ evaluation board for smart driver
System design
3.3

Bill of material

The complete bill of material (BOM) is available in the download section on the homepage of Infineon's
website. Login credentials are required to download this material. Table 9 lists the BOM of EVAL-M7-D112T.
BOM of the most important/critical parts of the evaluation board
Table 9
S.
Ref Designator
No.
1 C1, C3, C18, C19,
C22, C29, C101,
C102, C103, C104,
C108, C110, C111
2 C2, C7, C10, C13,
C14, C25, C26, C27,
C28
3 C4, C5, C6, C8, C9
4 C11
5 C12, C16
6 C15, C20, C109,
C113
7 C17
8 C21, C23, C24
9 C30, C31, C32
10 C105, C114, C115
Description
CAP / CERA / 100 nF / 50 V / 5% /
X7R (EIA) / -55℃ to 125℃ / 603 /
SMD / -, CAP / - / 100 nF / 16 V / 5%
/ X7R (EIA) / - / 0603 / SMD
CAP / CERA / 4.7 nF / 50 V / 5% /
C0G (EIA) / NP0 / -55℃ to 125℃ /
0603(1608) / SMD / -, CAP / CERA /
4.7 nF / 25 V / 5% / X7R (EIA) / -
55℃ to 125℃ / 0603(1608) / SMD
CAP / CERA / 220 pF / 50 V / 2% /
C0G (EIA) / NP0 / -55℃ to 125℃ /
0603(1608) / SMD / -
CAP / CERA / 10 nF / 50 V / 10% /
X5R (EIA) / -55℃ to 85℃ /
0603(1608) / SMD / -
CAP / CERA / 1 nF / 50 V / 1% / C0G
(EIA) / NP0 / -55℃ to 125℃ /
0603(1608) / SMD / -
CAP / CERA / 1 uF / 25 V / 10% /
X5R (EIA) / -55℃ to 85℃ /
0603(1608) / SMD / -, CAP / CERA /
1 uF / 10 V / 10% / X5R (EIA) / -55℃
to 85℃ / 0603(1608) / SMD / -
CAP / CERA / 4.7 uF / 25 V / 10% /
X5R (EIA) / -55℃ to 85℃ /
0805(2012) / SMD / -
CAP / CERA / 1 uF / 50 V / 10% /
X7R (EIA) / -55℃ to 125℃ / 0805 /
SMD / -
CAP / CERA / 4.7 nF / 25 V / 1% /
C0G (EIA) / NP0 / -55℃ to 125℃ /
0603 / SMD / -
CAP / CERA / 10 uF / 10 V / 20% /
X7T (EIA) / -55℃ to 125℃ /
0603(1608) / SMD / -
Manufacturer
AVX
MuRata
Kemet
MuRata
Kemet
MuRata
MuRata
TDK
Corporation
Kemet
MuRata
18
Manufacturer P/N
06035C104JAT2A
GRM1885C1H472JA01
C0603C221G5GAC
GRM188R61H103KA01
C0603C102F5GAC
GRM188R61E105KAAD
GRM219R61E475KA73
CGA4J3X7R1H105K125AB
C0603C472F3GAC
GRM188D71A106MA73D
