EVAL-M1-IM523 user guide
iMotionTM modular application design kit
System design
Quantity Ref Designator
1 C48
1 C49
2 C50, C57
1 C51
1 C54
1 C55
4 D1, D2, D4, D5
1 D3
1 D6
1 D7
1 D8
1 D9
1 D10
1 F1
1 Fan
1 Fuse1
2 J1, J2
1 J3
1 L1
1 L2
1 LED1
1 MP1
3 MP2, MP3, MP4
MP5, MP6, MP7,
4
MP8
MP9, MP10, MP11,
4
MP12
Description
CAP / ELCO / 100uF / 35V / 20% /
Aluminiumelectrolytic / -40℃ to 85℃ /
2.50mm C X 0.50mm W 6.30mm Dia X
12.50mm H / - / -
CAP / CERA / 1nF / / 20% / E (JIS) / -40℃
to 125℃ / 7.50mm C X 0.60mm W
7.00mm L X 7.00mm T X 10.00mm H /
THT / -
CAP / CERA / 1nF / 16V / 10% / X7R (EIA)
/ -55℃ to 125℃ / 0603(1608) / SMD
CAP / CERA / 220nF / 25V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0603(1608) / SMD
CAP / CERA / 2.2nF / 50V / 10% / X5R
(EIA) / -55℃ to 85℃ / 0603(1608) / SMD
CAP / ELCO / 47uF / 25V / 20% /
Aluminiumelectrolytic / -40℃ to 105℃ /
2.00mm C X 0.50mm W 5.00mm Dia X
12.50mm H / THT / -
Surface Mount Fast Switching Diode
Glass Passivated Bridge Rectifier 600V
High Voltage Surface-Mount Schottky
Rectifier, VRRM 100V
Surface Mount Ultrafast Rectifier
1.0A/1000V
Surface-Mount Schottky Barrier Rectifier,
VRRM 45V
Super Fast Recovery Diode, VR 200 V, IF
1 A
Zener Diode, 5% 13V
FUSE CERAMIC 12.5A 250VAC
125VDC,5x20mm
DC Axial Fan for omniCOOL bearing
system,50 x 50 mm frame. Mulitple Speed
options
Fuse Holder Block, PCB Clip Cover, 18A,
250VAC
Horizontal Cable Entry with Rising Cage
Clamp - WR-TBL, 3Pins
Header, 2.54mm Pitch, 2 pin, Vertical,
Single Row
IND / STD / 12mH / 10A / 50% / -40℃ to
125℃ / 15mR / THT / Inductor, THT, 4 pin,
23.00 mm L X 34.00 mm W X 33.00 mm H
body / THT / -
IND / STD / 2.2uH / 2.5A / 20% / -40℃ to
125℃ / 71mR / SMD / Inductor, SMD; 2-
Leads, 4.50 mm L X 4 mm W X 3.50 mm H
body / SMD / -
LED 3mm Red Through Hole Lamp
Standard Heatsink
M3 Metric Countersunk Head Screw,
Length 10mm
Pan Head Screw, M3X0.5
WA-SSTIE Steel Spacer Stud, M3
19
Manufacturer Manufacturer P/N
Wurth Elektronik 860010573007'
MuRata DE6E3KJ102MN3A
C0603C102K4RACTU,
Kemet
C0603C102F5GAC
MuRata GRM188R61E224KA88
MuRata GRM188R61H222KA01
Wurth Elektronik 860020472006'
Diodes Incorporated 1N4148W-7-F
Micro Commercial
GBJ1006-BP
Components
Vishay SS2H10-E3/52T
Vishay US1M-E3/61T
Vishay BYS10-45-E3/TR3
ROHM
RF071MM2STR
Semiconductors
Solid State Devices
SZ25B13SM
Inc.
Schurter 0001.2715.11
CUI CFM-5015V-138-201
Wurth Elektronik 696101000002'
Wurth Elektronik 691216510003S
Wurth Elektronik 61300211121
Wurth Elektronik 7448051012
Wurth Elektronik 744773022
LiteOn
LTL-1CHEE
Optoelectronics
Infineon Technologies HS-5050-100
Duratool M310 KRSTMCZ100-
Keystone Electronics
9191-4
Corp.
Wurth Elektronik 971060321
