EVAL-M1-IM523 user guide
iMotionTM modular application design kit
System design
Quantity Ref Designator
1 R49
2 R52, R53
1 R54
1 R55
1 R57
1 RS1
2 RS2, RS3
1 RY1
1 TR1
1 U1
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U8
X1, X2, X3, X4, X5,
6
X6
1 X7
3 X8, X9, X10
X11, X12, X14, X15,
7
X16, X17, X19
X13, X20, X21, X22,
5
X23
1 X18
1 ZD1
Description
RES / STD / 9.76k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603 / SMD
RES / STD / 2k / 100mW / 1% / 100ppm/K
/ -55℃ to 155℃ / 0603(1608) / SMD
RES / STD / 9.1k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603(1608) /
SMD
RES / STD / 1k / 100mW / 1% / 100ppm/K
/ -55℃ to 155℃ / 0603(1608) / SMD
RES / STD / 390k / 100mW / 1% /
100ppm/K / -55℃ to 155℃ / 0603(1608) /
SMD / -
RES / STD / 10mR / 3W / 1% / 50ppm/K / -
55℃ to 170℃ / 2512(6332) / SMD / -
RES / STD / 5.1R / 250mW / 1% /
100ppm/K / -55℃ to 155℃ / 1206 / SMD / -
RELAY GENRAL PURPOSE SPST 20A
12V
Flyback Transformer, Offline aux SMPS for
server, PC power applications
CIPOS Mini IM523
Dual Comparators
11MHz, Rail-to-Rail I/O CMOS Operational
Amplifiers
Low Dropout Linear Voltage Regulator, 5.0
V Output
Optocoupler, Phototransistor Output, High
Reliability, 5300 VRMS, 110℃ Rated
Fixed Frequency 700 V/800 V CoolSET,
lowest standby power <100 mW
Precision Programmable Reference
Low-Power Single Voltage Comparator
Test Point THT, Yellow
WR-PHD 2.54 mm Angled Dual Socket
Header
Test Point THT, White
Test Point THT, Orange
Test Point THT, Black
Horizontal Cable Entry with Rising Cage
Clamp - WR-TBL, 2 Pins
Zener Diode with Surge Current
Specification
21
Manufacturer Manufacturer P/N
Vishay CRCW06039K76FK
Vishay CRCW06032K00FK
Vishay CRCW06039K10FK
Yageo RC0603FR-071KL
Vishay CRCW0603390KFK
Bourns CRA2512-FZ-R010ELF
Vishay CRCW12065R10FK
Omron G4A-1A-PE 12VDC
Wurth Elektronik 750344226
Infineon Technologies IM523-X6A
Texas Instruments LM393ADR
- SGM721XN5/TR
Infineon Technologies TLE42744DV50
Vishay SFH617A-3X007T
Infineon Technologies ICE5GR4780AG
Texas Instruments TL431CDBZR
STMicroelectronics TS391RIYLT
Keystone Electronics
5004
Corp.
Wurth Elektronik 613020243121'
Keystone Electronics
5002
Corp.
Keystone Electronics
5003
Corp.
Keystone Electronics
5001
Corp.
Wurth Elektronik 691216510002S
Vishay BZD27C22P-HE3-08
Revision 1.00
2023-01-16
