System performance
85
75
65
55
45
35
25
Figure 24 IPM ΔTc Vs. motor phase current at different PWM
Figure 25 Iu & Flx_M at 15 kHz PWM, 220 V
IPM ΔTc Vs. motor phase current at different PWM
2.065 3.009
motor phase current (Arms)
input, 900 W output (5.5 A
AC
4.037 5.512
phase current)
rms
27
4kHz
6kHz
10kHz
15kHz
20kHz
