Installer Menu
6.9.2

RF Test

RF testing checks the signal strength of all the wireless devices enrolled to the
system. If a weak signal is detected, a repeater may be used to improve the
link quality.
The system saves the most recent set of RF test results for uploading. The
system clears the tests when running another RF test.
To perform the test:
1. Using the Menu button select the test you wish to perform, and press the
Enter button to access the test.
2. Activate the RF unit to send a signal to the unit. The results can be
Normal Low
or
 Test Detectors
Test R. Controls

 Test R. Siren
 Test Keypads
Test Repeaters

To v iew the results:
1. For each of the tests, you can review the results by pressing the Enter
button and then either the Menu button or the alphanumeric keys review
all the units.
To exit the RF test mode you must press the ESC button.
2.
6.9.3

Test Indicators

The indicators test checks the two indicator LEDs, power and status, located on
the Panel.
To test the indicators:
After entering this menu, press Enter. The LEDs blink three times.
6.9.4

Sirens test

This test checks the different available sirens by activating them.
To test the sirens:
1. Select the siren you wish to test:
 Local Siren
 External siren
 RF siren
Siren 1

 Siren 2
Siren 3

 Siren 4
Press Enter to activate the sounder.
2.
Press ESC to stop the siren.
3.
54
. The available tests are:
Strong
HLX-40 Installer Manual
,
