Installer Menu
CS Primary
i.
communication types. Press Enter to confirm.
CS Secondary
ii.
GSM communication types. Press Enter to confirm.
If the GSM stick is not installed, the Link Type is set to PSTN, and cannot be
changed.
6.6.5

Line Test

Enables you to specify the time when the phone line and CS reporting are
tested and reported to the central station, as well as the time interval between
each test (periodic reporting).
To set up line test:
1. Using the Menu button, select one of the two options to define, and
press Enter to confirm:
Repeats – Specify the number of days between tests. Using the

numeric keypad, choose 1 to 30 days press Enter to save; default is
7.
Test_Time – Specify the hour of the day to perform the line test.

Using the numeric keypad, type the four digits of the desired hour
(24H convention), press Enter to save. The test time is set at 12:00 by
default.
6.6.6

AC Fail Report

This option allows you to specify a delay time, before reporting the power
failure to the CS, in which time power may be restored. The time is set to 0
(disabled) by default.
Power (AC) failure is indicated by the Power LED, which flashes green.
To set up AC fail report:
1. Using the numeric keypad, set the time between 1–240 minutes, or set it
to 0 to disable the option.
2. Press Enter to confirm and save your selection.
6.6.7

Fax Defeat

When calling the system, fax and answering machines may need to be
overridden. This menu specifies whether to enable or disable this override. By
default, this option is disabled.
To set up Fax Defeat:
Using the Menu button, Enable or Disable the option.
1.
Press Enter to confirm.
2.
48
– Using the Menu button, select either PSTN or GSM
– Using the Menu button, select either PSTN or
