Installer Menu
6.4.2

Remote Controls

You can enroll up to eight remote controls and specify functions for each
button on the remote control. You can also delete enrolled remote controls.
To enroll a remote control and specify a function:
1. Select the desired remote control number 01–08 by either browsing the
remotes using the Menu button or by entering the remote number using
the numeric keypad.
2. Enroll the remote control when the
displayed, by pressing a button on the remote you wish to enroll.
When the signal is detected you are asked to press the Enter button to
3.
store and save your selection.
4. Once the selection is stored, you can then choose to configure each of the
remote control buttons to behave in one of the following options:
 Restore Default (sets the button to its original functionality)
Operate PGM 1

 Operate PGM 2
Status Request

At any time press the ESC button to exit the menu.
5.
Once you exit the menu (after saving the enrollment) you cannot change the
button's behavior, unless you delete the remote and re-enroll it.
To delete a remote control
1. Select the pre-enrolled remote control number 01–08 by either browsing
the list of remotes using the Menu button or by entering the remote
number using the numeric keypad.
You are asked to confirm deletion.
2. Press Enter to delete the detector or the ESC button to go back.
6.4.3

RF Siren

You can enroll up to four RF sirens. You can choose to remove enrolled sirens.
To enroll/ remov e an RF siren:
1. Select the required Siren location, #01–04 by either browsing the keys
using the Menu button or by entering the siren's number using the
numeric keypad.
2. Enroll the RF Siren when the
activating the siren's tamper.
3. When the signal is detected, you are asked to press the Enter button to
store and save your selection
If the selected location has a siren enrolled, you are asked whether you
wish to delete it.
4. Press the Enter button to delete or the ESC button to go back.
HLX-40 Installer Manual
WAITING FOR SIGNAL
WAITING FOR SIGNAL
message is
option is displayed by
33
