ADRF6650-EVALZ

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty. Reference Designator
26
C1, C4, C26, C32, C35, C51, C53, C56,
C57, C61, C66, C72, C80, C90, C93, C94,
C130, C131, C132, C133, C158, C170,
R13, R14, R15, R16
3 C10, C96, C97
28 C9, C12, C15, C16, C21, C23, C24, C27,
C30, C34, C36, C38, C39, C40, C41, C44,
C45, C52, C59, C67, C71, C83, C84, C85,
C87, C89, C100, C101
10 C98, C102, C108, C111, C113, C129,
C135, C136, C138, C139
4 C11, C47, C48, C103
4 C43, C46, C104, C109
2 C106, C110
8 C13, C14, C18, C22, C37, C42, C49, C50
1 C134
1 C166
1 C167
1 C168
1 C169
1 C172
1 C173
4 C58, C60, C62, C64
2 C63, C82
1 C81
1 DS1
1 DS2
4 E1 to E4
2 E10, E11
11 J1 to J9, J12, J13
4 J10, J11, J14, J15
2 L1, L2
16 L7 to L22
2 L23, L24
1 L25
User Guide
Description
Ceramic capacitors, X7R, general-purpose,
0.1 μF, C0402, 16 V
Ceramic capacitors, X5R, general-purpose,
22 μF, C0603, 10 V
Ceramic capacitors, C0G (NP0), general-
purpose, 100 pF, C0402, 50 V
Ceramic capacitors, X5R, general-purpose,
10 μF, C0603, 25 V
Ceramic capacitors, X5R, 10 μF, C0402, 10 V Samsung
Ceramic capacitors, X5R, general-purpose,
1 μF, C0402, 16 V
Ceramic capacitors, X7R, general-purpose,
1000 pF, C0402, 50 V
Ceramic capacitors, chip multilayer, X7R,
0.1 μF, C0603, 50 V
Ceramic capacitor, X5R, 4.7 μF, C0603, 16 V TDK
Ceramic capacitor, X6S, general-purpose,
4.7 μF, C0603, 16 V
Ceramic capacitor, multilayer, X5R, 0.47 μF,
C0402, 16 V
Ceramic capacitor, 0.033 μF, C0402, 50 V
Ceramic capacitor, chip, X5R, 2.2 μF,
C0402, 6.3 V
Ceramic capacitor, X5R, general-purpose,
0.1 μF, C0402, 10 V
Ceramic capacitor, multilayer, NP0, 10 pF,
C0402, 50 V
Resistors, film surface-mount device, 39 Ω,
R0402, 1/16 W
Ceramic capacitors, U2J, general-purpose,
4300 pF, C0402, 10 V
Ceramic capacitors, chip, 0.12 μF, C0402, 50 V Kemet
LED, low current (green)
LED, AllnGaP, 560 nm, green, LED1206H77 Dialight
Inductor chip ferrite beads, 120 Ω, L0402
Inductor chip ferrite beads, 470 Ω, L0402
PCB connectors, SMA, 50 Ω, end launch
jack receptor
PCB connectors, coaxial, SMA, standard
Inductors, surface mount, 1 nH, L0402-2
Inductor chip ferrite beads, 120 Ω, L0603
Inductor surface mounts, 150 nH, 0603CS
Inductors, shielded power, 6.8 μH,
LSMSQ157H122
Rev. A | Page 15 of 17
Manufacturer Part Number
Murata GRM155R71C104KA88D
Murata GRM188R61A226ME15D
Murata GRM1555C1H101JA01D
Murata GRM188R61E106MA73D
CL05A106MP5NUNC
Murata GRM155R61C105MA12
Murata GRM15XR71H102KA86
Vishay VJ0603Y104KXA
C1608X5R1C475K080AC
Murata GRM188C81C475KE11D
TDK C1005X5R1C474K
Panasonic 0402YD333KAT2A
TDK C1005X5R0J225M
Murata GRM155R61A104KA01D
Yageo CC0402JRNP09BN100
Panasonic ERJ-2GEJ390X
Murata GRM1557U1A432JA01D
C0402C124J5RAC
ROHM SML-P11MTT86
597-3311-407NF
Murata BLM15EG121SN1D
Manufacturing
Murata BLM15BB470SN1D
Manufacturing
Cinch Connectivity 142-0701-851
Solutions
Cinch Connectivity 142-0701-201
Solutions
Coilcraft 0402CS-1N0XJLW
Murata BLM18KG121TN1D
Manufacturing
Coilcraft 0603CS-R15XJLW
Coilcraft XAL4030-682MEC
UG-1026
