Analog Devices ADRF6650-EVALZ User Manual page 16

UG-1026
Qty. Reference Designator
4 L3 to L6
7 P1 to P6, P10
1 P9
1 Q1
4 R1, R2, R69, R99
4 R9 to R12
64 R3, R4, R21 to R25, R28 to R32, R37 to
R39, R41, R44, R46, R48, R49, R50, R54,
R79, R80, R87 to R89, R97, R105 to
R109, R112, R113, R115 to R117, R119,
R120, R127, R129, R130, R136 to R142,
R145, R146, R148 to R150, R152, R154,
R156, R159 to R164
1 R110
9 R72 to R74, R114, R121 to R125
1 R135
4 R57, R62, R70, R143
3 R82, R84, R153
4 R17 to R20
2 R26, R27
1 R55
1 R56
1 R60
1 R61
2 R63, R86
1 R64
4 R65 to R68
4 R75 to R78
1 R81
1 R91
1 R93
1 R94
1 R95
1 R96
2 T1, T2
Description
Inductor surface mount, 270 nH, 0603CS
PCB connectors, BERG header, solder
termination, male, 3-pin
PCB connector, board to board receptacle,
solder termination, 0.6 mm pitch
Transistor, NPNj surface mount, small
signal, SOT23
Resistors, metal film chip, 5.1 kΩ, R0402,
25 V, 1/16 W
Resistor, high frequency thin film chip,
25 Ω, R0402, 0.05 W
Resistors, chip surface mount device
jumper, 0 Ω, R0402
Resistor, precision thick film chip, 11 kΩ,
R0402, 1/10 W
Resistors, thick film chip, 100 kΩ, R0402,
1/10 W
Resistor, film surface mount device, 51 Ω,
R0402, 1/16 W
Resistor, film surface mount device, 0 Ω,
R0603, 1/10 W
Resistors, standard thick film chip, 10 kΩ,
R0402, 1/16 W
Resistors, general purpose chip, 35.7 Ω,
R0402, 1/16 W
Resistors, thick film chip, 220 Ω, R0402,
1/16 W
Resistor, precision thick film chip, 47 kΩ,
R0402, 1/16 W
Resistor, thin film chip, 15 kΩ, R0603, 1/10 W
Resistor, precision thick film chip, 27 kΩ,
R0402, 1/16 W
Resistor, precision thick film chip, 140 Ω,
R0402, 1/16 W
Resistor, precision thick film chip, 4.7 kΩ,
R0402, 1/16 W
Resistor, standard thick film chip, 71.5 kΩ,
R0402, 1/16 W
Resistors, thick film, 0.1 Ω, R0402, 1/6 W
Resistors, precision thick film chip, 1 kΩ,
R0402, 1/10 W
Resistor, film surface-mount device,
1.1 kΩ, R0402, 1/16 W
Resistors, precision thick film chip, 10 Ω,
R0402, 1/16 W
Resistors, precision thick film chip, 150 Ω,
R0402, 1/10 W
Resistors, precision thick film chip, 130 Ω,
R0402, 1/16 W
Resistors, precision thick film chip, 100 Ω,
R0402, 1/10 W
Resistor, thick film chip, 47 Ω, R0402, 1/10 W
RF transformer
Rev. A | Page 16 of 17
ADRF6650-EVALZ
Manufacturer Part Number
Coilcraft 0603CS-R27XGLW
Samtec TSW-103-08-G-S
Hirose Electric FX8-120S-SV(21)
Diodes Incorporated BC848C-7-F
Panasonic ERA-2AEB512X
Vishay Precision CH0402-25RJFPT
Group
Panasonic ERJ-2GE0R00X
Panasonic ERJ-2RKF1102X
Panasonic ERJ-2GEJ104X
Panasonic ERJ-2GEJ510X
Panasonic ERJ-3GEY0R00V
Vishay Precision Group CRCW040210K0JNED
Yageo RC0402FR-0735R7L
Multicomp 0402WGF2200TCE
Panasonic ERJ-2RKF4702X
Yageo RT0603BRB0715KL
Panasonic ERJ-2RKF2702X
Panasonic ERJ-2RKF1400X
Panasonic ERJ-2RKF4701X
Vishay Precision Group CRCW040271K5FKED
Panasonic ERJ-2BSFR10X
Panasonic ERJ-2RKF1001X
Panasonic ERJ-2GEJ112X
Panasonic ERJ-2RKF10R0X
Panasonic ERJ-2RKF1500X
Panasonic ERJ-2RKF1300X
Panasonic ERJ-2RKF1000X
Panasonic ERJ-2GEJ470X
Mini Circuits TC1-1-13MX+
User Guide
