ACPL-355JC Reference Manual
A.4 Test Points
Table 13 lists the available test points for the EB1200M62-355JC.
Table 13: Available Test Points for the EB1200M62-355JC Evaluation Board
Test Point Designator
TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
TP10
TP11
TP12
TP13
TP14
TP15
TP16
TP17
TP18
TP19
TP20
TP21
TP22
Broadcom
Signal
VLDO
PWM_H (before buffer)
PWM_L (before buffer)
UVLO
FAULT
LED_IN_H (after buffer)
LED_IN_L (after buffer)
+V_QH
SOURCE_H
–V_QH
+V_QL
SOURCE_L
–V_QL
GATE_H
SOURCE_H
OC_H
GATE_L
SOURCE_L
OC_L
+5V_ISO
VOLTAGE
DC_BUS–
62-mm SiC Module EB1200M62-355JC Evaluation Board
