2.3 Pin Assignment

Pin assignment for all connectors on the EB1200M62-355JC is listed in the following sections.

2.3.1 Power Interface

The J1 power supply connector is used to supply all ICs and supply gate driver voltage, and
assignment. There are four screw terminals (J6, J7, J8, J9). Terminals J6 and J7 are used for connecting the drain terminals
of the half bridge switches to the OC pin of the gate driver, and terminals J8 and J9 are used for connecting to the high-
voltage DC rails (DC+, DC-) for voltage measurement.
Table 2: Pin Assignment of Connector J1 (Power Supply Connector)
Pin Label
1 +V_SUPPLY
2 GND
Table 3: Power Connectors J4, J5, J6, and J7
Designator Label
J6 DC+
J7 PHASE
J8 DC+
J9 DC-

2.3.2 Signal Interface

Table 4 to Table 7 list the pin assignments of connectors J2, J3, J4, and J5.
Table 4: Pin Assignment of Connector J2 (User Interface Connector)
Pin Label
1 VOLTAGE
2 GND
3 GND
4 MDAT
5 GND
6 MCLK
7 GND
8 GND
9 FAULT
10 UVLO
11 GND
12 PWM_L
13 PWM_H
14 GND
Broadcom
Function
Power supply for low-voltage side.
Ground.
Function
Terminal to the high-side switch drain connection for OC detection.
Terminal to the low-side switch drain connection for OC detection.
Terminal to the positive DC bus rail for voltage measurement.
Terminal to the negative DC bus rail for voltage measurement.
Function
Single-ended DC bus voltage measurement signal.
Ground.
Ground.
Data signal for sigma-delta current measurement.
Ground.
Clock signal for sigma-delta current measurement.
Ground.
Ground.
Fault signal for over-current protection of both drivers.
UVLO fault signal for both drivers.
Ground.
PWM signal for low-side driver.
PWM signal for high-side driver.
Ground.
Table 3 lists the functions for each of these connectors.
62-mm SiC Module EB1200M62-355JC Evaluation Board
Table 2 shows its pin
Direction
Output
Bidirectional
Bidirectional
Output
Bidirectional
Output
Bidirectional
Bidirectional
Output
Output
Bidirectional
Input
Input
Bidirectional
