- Page 1 BCM953158R Quick Start Guide Installation Guide Broadcom Confidential 953158R-IG100 October 10, 2017...
- Page 2 The term “Broadcom” refers to Broadcom Limited and/or its subsidiaries. For more information, please visit www.broadcom.com. Broadcom reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design. Information furnished by Broadcom is believed to be accurate and reliable. However, Broadcom does not assume any liability arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.
-
Page 3: Table Of Contents
BCM953158R Installation Guide Quick Start Guide Table of Contents 1 Introduction ..................................4 2 System ..................................5 2.1 Power...................................5 2.2 Memory – SPI Flash ............................5 2.3 Console – UM Mode ............................5 2.4 GUI – WM Mode ..............................6 3 Debug Interface ................................7 3.1 UART–J3408 ...............................7 3.2 SPI–J1601 ................................8... -
Page 4: Introduction
Quick Start Guide 1 Introduction The BCM953158R is a reference design board for the small-package series of the BCM5315X/BCM5316X. The configuration is eight GB copper ports and two 10 GB fiber ports. The operation mode supports UM and ROBO-OS depending on the SPI-Flash size. The reference board is shown in... -
Page 5: System
BCM953158R Installation Guide Quick Start Guide 2 System 2.1 Power 12VDC/1A (2.5 mm), the power adapter of the SVK board (BCM953158K/BCM953162K) is available as well. 2.2 Memory – SPI Flash U1901: MX25L8035EM1I-10G (8 Mbit by default for UM mode only) ... -
Page 6: Gui - Wm Mode
BCM953158R Installation Guide Quick Start Guide 2.4 GUI – WM Mode The default IP for GUI access is 192.168.1.10. Figure 3 shows the GUI screen. Figure 3: GUI – WM Mode Broadcom Confidential 953158R-IG100... -
Page 7: Debug Interface
BCM953158R Installation Guide Quick Start Guide 3 Debug Interface The debug interface is described in the following sections. 3.1 UART–J3408 Figure 4: UART–J3408 UART-J3408 Table 1: UART-J3408 Pin Descriptions Function 3.3V MFIO0_UART_RXD MFIO1_UART_TXD To access the UART console interface, connect the TTL to UART transceiver module as shown in... -
Page 8: Spi-J1601
BCM953158R Installation Guide Quick Start Guide 3.2 SPI–J1601 Figure 6: SPI–J1601 SPI-J1601 Table 2: SPI Pin Descriptions Function 3.3V MOSI MISO Note: The J1601 header is connected to the BCM53158 SPI1 master interface by a default board BOM option (R9839, R9840, R9841, and R9842 are all installed with a 0-ohm resistor in their position A–C only). -
Page 9: Jtag-J2302
BCM953158R Installation Guide Quick Start Guide 3.3 JTAG–J2302 Figure 7: JTAG–J2302 Broadcom Confidential 953158R-IG100... -
Page 10: Led Behavior And Definitions
BCM953158R Installation Guide Quick Start Guide 4 LED Behavior and Definitions Figure 8 provides the locations for the LED indicators. Figure 8: LED Locations Activity Link status Table 3 provides the LED behaviors and definitions. Table 3: LED Behavior and Definitions... -
Page 11: Revision History
BCM953158R Installation Guide Quick Start Guide Revision History 953158R-IG100; October 10, 2017 Initial release. Broadcom Confidential 953158R-IG100...
