Quick Start Guide
BCM53242M
Management Reference Board
53242M-QSG100-R
16215 Alton Parkway • P.O. Box 57013 • Irvine, CA 92619-7013 • Phone: 949-450-8700 • Fax: 949-926-5203
04/02/07

Advertisement

loading
Need help?

Need help?

Do you have a question about the BCM53242M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Broadcom BCM53242M

Summary of Contents for Broadcom BCM53242M

  • Page 1 Quick Start Guide BCM53242M Management Reference Board 53242M-QSG100-R 16215 Alton Parkway • P.O. Box 57013 • Irvine, CA 92619-7013 • Phone: 949-450-8700 • Fax: 949-926-5203 04/02/07...
  • Page 2 , and the Connecting everything logo are among the trademarks of Broadcom Corporation and/or its affiliates in the United States, certain other countries and/or the EU. Any other trademarks or trade names mentioned are the property of their respective owners.

  • Page 3: Table Of Contents

    04/02/07 ABLE OF ONTENTS Overview ............................... 1 Connectors ..............................2 Setting up a Broadcom SDK Console Connection ................... 2 Terminal-to-Switch Connection....................... 2 Configuring the HyperTerminal Utility ..................... 2 Using the CLI ............................5 Schematics ..............................7 Bro adco m Co rp or atio n...
  • Page 4 BCM53242M Quick Start Guide 04/02/07 IST OF IGURES Figure 1: BCM53242M Block Diagram ......................1 Figure 2: BCM53242M Front View ........................1 Figure 3: Terminal-to-Switch Connection ......................2 Bro adco m C orp or atio n Page iv Document 53242M-QSG100-R...
  • Page 5 Quick Start Guide BCM53242M 04/02/07 IST OF ABLES Table 1: BCM53242M Connectors ........................2 Bro adco m Co rp or atio n Document 53242M-QSG100-R Page v...
  • Page 6 BCM53242M Quick Start Guide 04/02/07 Bro adco m C orp or atio n Page vi Document 53242M-QSG100-R...

  • Page 7: Overview

    BCM53242M management reference board. The Broadcom Software Development Kit (SDK) includes a Command Line Interface (CLI) for users to manage the BCM53242M reference board and monitor its performance. To access the SDK, connect a management console to the console port of the reference board.

  • Page 8: Connectors

    HyperTerminal is a Windows utility program for serial communications. To configure HyperTerminal, follow these steps: Start the HyperTerminal utility. Select the COM port to communicate with the BCM53242M reference board. B roadc om C or por ati on Page 2 Connectors...
  • Page 9 From the File menu, select Properties. In the Properties window, select the Settings tab. Configure the settings as shown in the following figure. B roadc om C or por ati on Document 53242M-QSG100-R Setting up a Broadcom SDK Console Connection Page 3...
  • Page 10 Click the ASCII Setup button to display the ASCII Setup window and configure the settings as shown in the following figure. Click OK. 10. Power up the BCM53242M reference board. B roadc om C or por ati on Page 4...

  • Page 11: Using The Cli

    To set a specific static IP address, use the following sequence of commands: BCM.0> shell ecos> ifconfig eth1 10.144.2.4 netmask 255.255.255.0 gw 10.144.2.1 ecos> save all B roadc om C or por ati on Document 53242M-QSG100-R Setting up a Broadcom SDK Console Connection Page 5...
  • Page 12 Quick Start Guide 04/02/07 Alternatively, to set the IP address via DHCP protocol, use the commands shown in the following example. B roadc om C or por ati on Page 6 Setting up a Broadcom SDK Console Connection Document 53242M-QSG100-R...

  • Page 13: Schematics

    Quick Start Guide BCM53242M 04/02/07 CHEMATICS BCM53242M schematics are shown in the following pages. B roadc om C or por ati on Document 53242M-QSG100-R Schematics Page 7...
  • Page 14 Magnetic Magnetic Magnetic Magnetic Magnetic RJ45 2X4 RJ45 2X4 RJ45 2X4 RJ45 RJ45 Broadcom Corporation Broadcom Corporation Broadcom Corporation 16215 Alton Parkway 16215 Alton Parkway 16215 Alton Parkway P.O. Box 57013 P.O. Box 57013 P.O. Box 57013 Irvine, CA. 92619-7013 Irvine, CA.
  • Page 15 BLACK BLACK BLACK BLACK TP10 TP10 TP11 TP11 TP12 TP12 TP13 TP13 TP14 TP14 Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title Power, Reset, Clock Power, Reset, Clock Power, Reset, Clock Size Size Size Document Number Document Number Document Number...
  • Page 16 RDN_12 RDN_12 5 TDP_12 TDP_12 TDP_12 5 TDN_12 TBI1_RBC1 TDN_12 TDN_12 5 TBI1_RBC0 BCM53242 BCM53242 Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title 5324 Integrated PHY, RGMII 5324 Integrated PHY, RGMII 5324 Integrated PHY, RGMII Size Size Size Document Number...
  • Page 17 Muruta:BLM11A601S 200mA, 600ohm @100Mhz +3.3V MOSI R192 R192 4.7K (DNI) 4.7K (DNI) +3.3V MISO R229 R229 AT93C46-SI10-2.7(DNI) AT93C46-SI10-2.7(DNI) Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title 5324 VDD 5324 VDD 5324 VDD Size Size Size Document Number Document Number...
  • Page 18 10uF RDP_0 RDP_8 RDP_0 3 RDP_8 3 TDP_0 TDP_8 TDP_0 3 TDP_8 3 TDN_0 TDN_8 TDN_0 3 TDN_8 3 Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title 5324 RJ45 5324 RJ45 5324 RJ45 Size Size Size Document Number Document Number...
  • Page 19 R560 A_SGIN+ C353 C353 B_SD 0.01uF 0.01uF R566 R566 B_SGIN+ R558 R558 100 (DNI) 100 (DNI) R564 R564 Broadcom Corporation Broadcom Corporation Broadcom Corporation R585 R585 R582 R582 R584 R584 R583 R583 C314 C314 100 (DNI) 100 (DNI) 0.01uF 0.01uF...
  • Page 20 10uF 10uF +3.3V C183 C183 VDDIO10 PLLDVSS 10uF 10uF 2.2uF 2.2uF 47uF 47uF VDDIO9 VDDIO8 VDDIO7 VDDIO6 Broadcom Corporation Broadcom Corporation Broadcom Corporation VDDIO5 VDDIO4 VDDIO3 Title Title Title VDDIO2 BCM5836, SDRAM BCM5836, SDRAM BCM5836, SDRAM VDDIO1 Size Size Size...
  • Page 21 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 10uF 10uF 10uF 10uF 47uF 47uF Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title BCM5836, Flash, 5221 BCM5836, Flash, 5221 BCM5836, Flash, 5221 Size Size Size Document Number Document Number Document Number...
  • Page 22 C153 C145 C145 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF /PWE /PSEN /SRAM_CS Broadcom Corporation Broadcom Corporation Broadcom Corporation Title Title Title Web Smart, TF331 Web Smart, TF331 Web Smart, TF331 Size Size Size Document Number Document Number Document Number...
  • Page 23 R536 150 R536 150 P22_2 R488 150 R488 150 P7_1 R496 150 R496 150 P15_1 R504 150 R504 150 P23_1 Broadcom Corporation Broadcom Corporation Broadcom Corporation R519 150 R519 150 P7_2 R527 150 R527 150 P15_2 R535 150 R535 150 P23_2...
  • Page 24 Fax: 949-926-5203 Broadcom Corporation reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design. Information furnished by Broadcom Corporation is believed to be accurate and reliable. However, Broadcom Corporation does not assume any liability arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.
