3.6 Evaluation of the EB1200M62-355JC

The EB1200M62-355JC enables users to evaluate the following items:
ACPL-355JC driver features

ACPL-C87B precision voltage sensor features

External current measurement based on ACPL-736J sigma-delta modulator features

Switching characteristics of the SiC power semiconductors in a 62-mm package

Half-bridge inverter basic features

Buck-boost basic features

For the evaluation of the power semiconductor switching characteristics, with the EB1200M62-355JC, it is recommended to
perform a double-pulse test and measure the switching transients related to the semiconductor and the ACPL-355JC gate
driver circuit.
