- Page 1 Quick Start Guide for the BCM95389/BCM95396 Reference Board 04/29/05 16215 Alton Parkway • P.O. Box 57013 • Irvine, CA 92619-7013 • Phone: 949-450-8700 • Fax: 949-450-8710...
- Page 2 , and the Connecting everything logo are among the trademarks of Broadcom Corporation and/or its affiliates in the United States, certain other countries and/or the EU. Any other trademarks or trade names mentioned are the property of their respective owners.
-
Page 3: Table Of Contents
ABLE OF ONTENTS Overview ......................1 Block Diagram ....................2 Connector Settings ..................3 Setting Up a WebSmart™ Console Connection ........4 Terminal-to-WebSmart™ Connection ..........4 Configuring the HyperTerminal Utility ..........5 Setting Up a WebSmart™ Web-Based Connection ........8 B r oa dc om C or po ra t io n Document 95389_95396-QS100-R Page iii... - Page 4 BCM95389/BCM95396 B ro ad co m C or por a t ion Page iv Document 95389_95396-QS100-R...
- Page 5 IST OF IGURES 1: BCM95389 Block Diagram................2 2: BCM95396 Block Diagram................2 3: Terminal-to-WebSmart Connection..............4 4: WebSmart Web-Based Connection..............8 B r oa dc om C or po ra t io n Document 95389_95396-QS100-R Page v...
- Page 6 IST OF ABLES Table 1: BCM95389 Connector Settings ............3 Table 2: BCM95396 Connector Settings ............3 B r oa dc om C or po ra t io n Document 95389_95396-QS100-R Page vi...
-
Page 7: Overview
WebSmart common language infrastructure (CLI). • A network connection from one of the ports of the BCM95389/ BCM95396 reference board to a client Web browser. The user has access to the WebSmart web-based GUI interface. B r oadco m C or por ati on... -
Page 8: Block Diagram
BCM95396 reference boards. BCM5389 BCM5464 BCM5464 Magnetics Magnetics Figure 1: BCM95389 Block Diagram Taifatech 5396 BCM5464 BCM5464 BCM5464 BCM5464 Magnetics Magnetics Magnetics Magnetics Figure 2: BCM95396 Block Diagram Br oadc om C or por ati on Page 2 Document 95389_95396-QS100-R... -
Page 9: Connector Settings
Mux components connecting to SPI/EEPROM pins. 1–2: EEPROM (U12)/ 6-pin jumper (J4) 2–3: Microcontroller (U7) Power 5V/300A DC power source Connector Table 2: BCM95396 Connector Settings Number Settings SPI header/6-pins OPEN: For Websmart/microcontroller (8051) mode CLOSE: For SPI mode CPU_EPROM_SEL strap pin setting. -
Page 10: Setting Up A Websmart™ Console Connection
BCM95389/BCM95396 Table 2: BCM95396 Connector Settings (Continued) Number Settings Mux components connecting to SPI/EEPROM pins. 1–2: 8051 mode 2–3: Websmart mode Mux components connecting to SPI/EEPROM pins. 1–2: 8051 mode 2–3: Websmart mode AL-A250ATX MAX250W power source Setting Up a WebSmart™ Console Connection ™... -
Page 11: Configuring The Hyperterminal Utility
HyperTerminal is a Windows utility program for serial communications. To configure HyperTerminal, follow these steps: Start the HyperTerminal utility. Select the COM port to communicate with the BCM95389/BCM95396 demo target board. Set the serial port properties: • Bits per second: 19200 bps •... - Page 12 From the Properties menu select the Settings tab. Click the ASCII Setup button to display the ASCII Setup window. Click OK. Power up in the BCM95389/BCM95396 reference board. If communication is successful, the WebSmart CLI prompt appears on the screen as shown below:...
- Page 13 BCM95389/BCM95396 Setting Up a WebSmart™ Console Connection The BCM95389/BCM95396 WebSmart CLI prompts can be viewed by typing h for Help Menu. Typing <enter> afterward is not necessary. The initial network setting can be viewed by typing ng. Typing <enter> afterward is not necessary. The display appears as shown below: To customize these settings, type ns at the prompt.
-
Page 14: Setting Up A Websmart™ Web-Based Connection
BCM95389/BCM95396 Setting Up a WebSmart™ Web-Based Connection Connect both the client station and the BCM95389/BCM95396 reference board to a common network. The BCM95389/BCM95396 reference board connects via one of its network ports. Broadcom Switch Switch RJ-45 Client System Network Port... - Page 15 BCM95389/BCM95396 Setting Up a WebSmart™ Web-Based Connection Type the IP address corresponding to the BCM95389/BCM95396 reference board. If the address has not been changed either manually (by issuing the ns command) or by the DHCP, the default address is 192.168.0.234. The browser address box should then be http:// 192.168.0.234.
- Page 16 Corporation reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design. Information furnished by Broadcom Corporation is believed to be accurate and reliable. However, Broadcom Corporation does not assume any liability arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.
