1.5.9
Side I/O Slots
The I/O connectors accessible from the right side panel of the
DLAP-211 are described below.
SD Card Slot
For additional storage, use the side door to install or remove a
user-provided SD card.
USIM Slot
The DLAP-211 is equipped with a USIM slot connected to the
Mini PCIe connector for use with a user-provided SIM card and
3G/4G Mini PCIe module to provide cellular communication.
Install or remove a SIM card module via the side door.
The 3G/4G Mini PCIe module requires a user-provided SIM
card for communication via a telecom operator. See
Section 2.5 Installing a Mini PCIe Wi-Fi Module on page 21.
NOTE:
NOTE:
Introduction
DLAP-211-JNX / DLAP-211-JT2 / DLAP-211-Nano Series
Figure 1-8: USIM / SD Side Door
15
