7. Settings

7.1 Setting BMS address

Refer to "Setting the BMS address" on page

7.2 Setting an alarm for insulation faults

You can set the limit values for alarm 1 and alarm 2 of the ISOMETER® via the BMS bus by
means of a BMS gateway (e.g. COM460IP) or a terminal program. Activation or deactivation
of the two alarm levels R
graphic:
An alarm will become inactive as soon as the hysteresis of the set operating value is excee-
ded.
R
R
an1
R
an2
Alarm 1
aktiv
One insulation resistance from 200 Ω...1 MΩ can be set respectively for alarm 1 and alarm
2. Condition: alarm 1 ≥ alarm 2.
30
for alarm 1 and R
an1
Alarm 2
aktiv
37.
for alarm 2 are illustrated in the following
an2
Hysterese
Hysterese
Alarm 2 Alarm 1
inaktiv inaktiv
isoPV1685xxx_D00007_08_M_XXEN/03.2023
Settings
t
