5.2.3 Connecting the EDS to the ISOMETER® isoxx1685DP
Risk of malfunctions due to excessive locating current on
sensitive system parts!
The locating current flowing between the IT system and earth can
CAUTION
cause controller faults in sensitive parts of the system, such as the PLC
or relay. Ensure that the level of the locating current is compatible
with the system to be monitored
Risk of incorrect measurement
The supplied locating current may influence other connected
insulation fault location systems. If they measure the injected
locating current, the measurement might be incorrect..
Insulation monitoring is deactivated while the insulation fault
location is active.
