Connection of the system coupling
Connection type ........................................................................................................................ pluggable push-wire terminals
Connection, rigid/flexible.................................................................................................................. 0.2...10 mm
Connection, flexible with ferrule, without/with plastic sleeve .................................................... 0.25...6 mm
Conductor sizes (AWG).................................................................................................................................................... 24...8
Stripping length ............................................................................................................................................................... 15 mm
Opening force ........................................................................................................................................................... 90...120 N
Environment/EMC
EMC .......................................................................................................................................................... IEC 61326-2-4 Ed. 1.0
Classification of climatic conditions acc. to IEC 60721:
Without solar radiation, precipitation, water, icing. Condensation possible temporarily:
Stationary use (IEC 60721-3-3) .......................................................................................................................................... 3K23
Transport (IEC 60721-3-2) .................................................................................................................................................. 2K11
Long-term storage (IEC 60721-3-1).................................................................................................................................. 1K22
Classification of mechanical conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3).......................................................................................................................................... 3M11
Transport (IEC 60721-3-2) .................................................................................................................................................. 2M4
Long-term storage (IEC 60721-3-1) ................................................................................................................................ 1M12
Deviation from the classification of climatic conditions:
Ambient temperature during operation ............................................................................................................ –40...+70 °C
Ambient temperature transport ........................................................................................................................ –40...+80 °C
Ambient temperature long-term storage ........................................................................................................ –25 ...+80 °C
Relative humidity ................................................................................................................................................... 10...100 %
Atmospheric pressure .................................................................................................... 700...1060 hPa (max. height 4000 m)
Other
Operating mode ....................................................................................................................................... continuous operation
Position of normal use............................................................................................................. vertical, system coupling on top
PCB fixation..................................................................................................................................... lens head screw DIN7985TX
Tightening torque..............................................................................................................................................................4.5 Nm
Degree of protection, internal components ......................................................................................................................... IP30
Degree of protection, terminals............................................................................................................................................ IP30
Weight.......................................................................................................................................................................... ≤ 1300 g
( )* = factory settings
46
isoPV1685xxx_D00007_08_M_XXEN/03.2023
Technical Data
2
2
/0.2...6 mm
2
2
/0.25...4 mm
