Installation and Session Startup
3. To connect to a new EZ-KIT Lite session, start Session Wizard by
selecting one of the following.
• From the Session menu, New Session.
• From the Session menu, Session List. Then click New Ses-
sion from the Session List dialog box.
• From the Session menu, Connect to Target. Then click
New Session from the Session List dialog box.
4. The Select Processor page of the wizard appears on the screen.
Ensure SHARC is selected in Processor family. In Choose a target
processor, select ADSP-21161N. Click Next.
5. The Select Connection Type page of the wizard appears on the
screen. Select EZ-KIT Lite and click Next.
6. The Select Platform page of the wizard appears on the screen.
In the Select your platform list, select ADSP-21161N EZ-KIT
Lite via Debug Agent. In Session name, highlight or specify the
session name.
The session name can be a string of any length; although, the box
displays approximately 32 characters. The session name can
include space characters. If you do not specify a session name,
VisualDSP++ creates a session name by combining the name of the
selected platform with the selected processor. The only way to
change a session name later is to delete the session and to open a
new session.
Click Next.
