Connectors
Part Description
20-position AMPMODU system
20 connector (w/o lock)
Flexible film contacts
(20 per connector)
Link Port Connectors (P13 and P14)
Each link port connects to a 26-pin connector. Refer to EE-106 found on
the ADI Web site at
the link port connectors.
Part Description
26-position connector
Cable connector
Shroud
Coaxial cable
Power Input Connector (P16)
The power input connector (
operate the EZ-KIT Lite board.
Part Description
2.5 mm power jack (
7V power supply
2-20
www.BDTIC.com/ADI
Manufacturer
AMP
AMP
http://www.analog.com
Manufacturer
HONDA
Mating Connectors
HONDA
HONDA
GORE
) provides all of the power necessary to
P16
Manufacturer
)
SWITCHCRAFT
P16
DIGI-KEY
Mating Power Supply (shipped with EZ-KIT Lite)
CUI STACK
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Part Number
2-487938-0
487547-1
for more information about
Part Number
RMCA-EA26LMY-0M03-A+
RMCA-E26F1S-A
RMCA-E26L1A
DXN2132
Part Number
RAPC712X
RAPC712X-ND
DTS070175SUDC-P6-SZ
