A ADSP-21161N EZ-KIT LITE
BILL OF MATERIALS
The bill of materials corresponds to
matic" on page
Devices Web site:
http://www.analog.com/processors/sharc/technicalLibrary/manu-
als/index.html#Evaluation%20Kit%20Manuals
Ref. Qty. Description
1 3 74LVC14A
SOIC14
2 1 MMBT4124
SOT-23
3 1 74LVC00AD
SOIC14
4 1 12.288MHZ
OSC001
5 1 25MHZ
OSC001
6 1 CS8416-CS
SOIC28
7 10 LMV722M
SOIC8
8 3 MT48LC8M16A
2P-6A TSOP54
9 1 74FCT244AT
QSOP20
